Hornby DIGITAL Bedienungsanleitung

7019 HB Select Walkabout A5 6pp:Layout 1 25/6/07 17:04
Connecting the Select Walkabout
1. Locate the XpressNet port situated at the rear of the Select Command Station unit and insert the R8236 RJ12 Connecting
Lead included with the Select Walkabout. LCD will display "03".
2. Locate the XpressNet port at the rear of the Select Walkabout unit and insert the other end of the R8236 RJ12
Connecting Lead. LCD will display "HC".
3. Press "SELECT" to confirm. LCD will display "Ad" (Address).
4. Insert a number (1-31) which will be the Walkabout's address. For this example, press "1" and then "SELECT".
The Red LED will flash 5 times. LCD will then display the default setting/locomotive "03".
5. The Select Walkabout is now ready for use.
Operation 1 Control of one locomotive by the Select and Select Walkabout.
Example 1a: Using locomotive No. 1
Select Unit: Press "1" and then "SELECT". LCD will display "1".
Walkabout: Press "1" and then "SELECT". LCD will display "1".
Both units will now have the ability to control locomotive No. 1.
Example 1b:
1. Turn the Select control knob so locomotive No. 1 starts to move.
2. Next turn the Select Walkabout control knob.The LCD, on the Select will flash "01" to
indicate control of the locomotive is now being handled by the Select Walkabout.
3. Now turn the Select control knob so that the locomotive stops and the Select Walkabout
LCD will start to flash.This denotes that the Select unit now has control.
4. Next turn the Select Walkabout control knob so that the locomotive starts to move.
The Select LCD display will not flash, indicating that the Select's control knob is fully in
the "Stop" position.
Operation 2 Controlling two or more different locomotives using the Select and
Select Walkabout.
Example 1: For this example locomotive Nos. 1 and 2 are assigned to the Select
and Select Walkabout.
1. Assign locomotive No. 1 to the Select. The LCD will display "01"
2. Using the Select Walkabout key pad assign locomotive No. 2 to the Select Walkabout.
The LCD will display "02"
3. Both units will now operate independently from each other.
4. Both units can be used to "call up" and address other locomotives as per the Operating
Instructions included with the Select.
It is possible for locomotives to be interchanged between the Select and the Select
Walkabout while they are in motion. During this operation the locomotive concerned
will remain at the set speed before being transferred. Once the control knob is moved
full control is obtained.
Either the Select or the Select Walkabout can be used to programme locomotives.
To program a locomotive, ensure all locomotives are removed from the track, other than the
one to be programmed, and disconnect all point decoders. It is recommended that a Programming
Track is used.
All other operating instructions for the Select Walkabout are the same as the Hornby Select
Controller. For further operating instructions please consult the Select operating manual.
Page 1
Safety Notes
This product is not suitable for children under 3 years because of small parts which can present a choking hazard. Some components have functional sharp points and edges.
G
Handle with care. This product is intended for indoor use only.
G
The transformer included is not a toy; it is a "Transformer for Toys".
G
event of such damage, the Select unit should not be used until the transformer is replaced with a new Hornby recommended unit. Never attempt to open the unit yourself.
Before cleaning any part, disconnect the transformer from the mains electricity supply.
G
inserted into outlets. The output terminals of the transformers must not be connected directly, or indirectly, to the output of any other mains power supply.
G
these details and the address for future reference.
Guarantee
All Hornby products are guaranteed against defects in materials and workmanship for a period of 6 months and Hornby Digital electronics for 1 year from the date of purchase.
To qualify for the guarantee, the product must have been used and maintained according to the manufacturers instructions, and will only be covered when used in conjunction
with officially approved Hornby accessories and components.While every possible care and attention has been taken by Hornby to ensure that the product arrives to you in
pristine condition, we cannot accept liability for any subsequent misuse of the product. It is the responsibility of the consumer to ensure that the product is maintained as per
the servicing details provided.
For reliable programming it is important that the track and wheels of all locomotives and wagons used with the Select Digital system are kept clean. If any defect occurs during
the guarantee period, then the item in the first instance should be returned to the place of original purchase.Alternatively, if any such defect occurs during the period of guarantee,
then please contact your Hornby Service dealer for advice. Or, the product (or component), may be forwarded to Hornby Hobbies Ltd, carefully packed, with a covering
letter enclosed giving full details to:
Repairs Department, Hornby Hobbies Ltd,Westwood, Margate, Kent CT9 4JX. UK.
Please include a copy of the original sales document showing the product reference number, date of purchase and from where purchased and any other requested information
relating to the product. Please obtain a Certificate of Posting at the time of despatch.
Exclusions
Subject to the exclusions below, the product will be repaired or replaced free of charge, if the problem is found to be due to either workmanship or materials.The repair/replacement
will be provided as promptly as possible without significant inconvenience to the consumer:
to the manufacturers recommendations.
diminish, your statutory rights. For further advice about your statutory rights contact your local authority Trading Standards Department or Citizens Advice Bureau.This warranty
only covers Hornby manufactured items. Please retain these details and address for future reference.
F
Remarques relatives à la sécurité
Ce produit ne convient pas aux enfants de moins de 36 mois car il comporte des petites pièces présentant des risques d'étouffement. Certains éléments ont des parties fonctionnelles pointues
G
et des rebords coupants. Manipuler avec précaution.
les transformateurs conseillés par Hornby.
G
présence de tout dégât éventuel sur le boîtier, les broches des prises et les câbles. En cas de dégât de ce genre, la console Select ne devra pas être utilisée jusqu'à ce que le transformateur ait été
remplacé par un nouvel appareil conseillé par Hornby. N'essayez jamais d'ouvrir vous-même la console.
secteur. G N'utilisez pas de liquide pour le nettoyage.
transformateurs à la sortie d'une autre alimentation électrique quelle qu'elle soit.
Exceptions
A l'exception des cas suivants, le produit sera réparé ou remplacé à titre gratuit si le problème s'avère être un vice matériel ou de fabrication. La réparation ou le remplacement seront effectués aussi
rapidement que possible sans que le consommateur ne subisse de gêne significative.
du fabricant. Dégât physique accidentel. Pour connaître vos droits en tant que consommateur de ce produit, veuillez consulter l'Institut national de la consommation. Cette garantie ne concerne
G
que les articles fabriqués par Hornby.Veuillez conserver ces informations et cette adresse pour référence ultérieure.
I
Avvertenze per la sicurezza
Questo prodotto non è adatto a bambini di età inferiore a 3 anni perché contiene elementi di piccole dimensioni che potrebbero essere inghiottiti con conseguente pericolo di soffocamento.Alcuni
G
componenti presentano parti funzionali acuminate. Manipolare con cautela.
deve essere utilizzato unicamente con trasformatori consigliati da Hornby.
il trasformatore, è consigliabile verificare l'assenza di danni all'alloggio, ai perni per le prese e ai cavi. Qualora venissero individuati danni, non utilizzare la centralina Select finché il trasformatore
non viene sostituito con un'unità raccomandata da Hornby. Non aprire la centralina.
utilizzare detergenti liquidi. I fili elettrici non devono essere inseriti nelle prese senza un mezzo per la connessione.
G
né indirettamente all'uscita di altre alimentazioni della rete.
Esclusioni
Il prodotto è soggetto alle esclusioni riportate di seguito, e viene riparato o sostituito a titolo gratuito quando il problema evidenziato va attribuito alla qualità dell'esecuzione o ai materiali utilizzati.
Ogni riparazione e sostituzione viene effettuata nel più breve tempo possibile per evitare gravi disagi al consumatore:
impiego contrario alle indicazioni dei produttori.
nazionale consumatori. La presente garanzia copre soltanto gli articoli di realizzazione Hornby. E' consigliabile conservare le informazioni e gli indirizzi indicati per eventuali consultazioni future.
D
Sicherheitshinweise
Dieses Produkt ist für Kinder unter 3 Jahren nicht geeignet, da es verschluckbare Kleinteile enthält, die ein Erstickungsrisiko darstellen können. Einige Komponente besitzen scharfe Stellen und
G
Kanten, die für den Betrieb erforderlich sind.Vorsichtig verwenden.
Hornby empfohlenen Transformatoren verwendet werden.
sollte der Transformator auf Beschädigungen am Gehäuse, an den Kabeln und den Steckern überprüft werden. Falls Anzeichen für derartige Beschädigungen vorhanden sind, darf die Anlage Select
erst in Betrieb genommen werden, nachdem der Transformator durch ein neues, von Hornby empfohlenes Gerät ersetzt wurde.Versuchen Sie niemals, das Gerät selbstständig zu öffnen.
Reinigung aller Teile muss der Transformator vom Stromnetz getrennt werden.
gesteckt werden. G Die Ausgangsklemmen der Transformatoren dürfen weder direkt noch indirekt an den Ausgang anderer Stromquellen angeschlossen werden.
sowie die Adresse für zukünftige Verwendung auf.
Ausschlüsse
Vorbehaltlich der folgenden Ausschlüsse wird das Produkt kostenlos repariert oder ersetzt, wenn festgestellt wird, dass das Problem auf Material- oder Verarbeitungsfehler zurückzuführen ist. Die
Reparatur bzw. der Austausch erfolgt so schnell wie möglich und weitestgehend ohne Unannehmlichkeiten für den Endverbraucher:
oder falsche, nicht den Empfehlungen des Herstellers entsprechende Nutzung verursacht oder ist diesen Umständen zuzuschreiben.
Rechten als Verbraucher im Zusammenhang mit diesem Produkt erhalten Sie von der nationalenVerbraucherzentrale. Diese Garantie deckt nur die von Hornby hergestellten Produkte ab. Bitte bewahren
Sie diese Details sowie die Adresse für zukünftige Verwendung auf.
E
Notas de seguridad
Este producto no es adecuado para niños menores de 3 años, ya que contiene piezas pequeñas que podrían causar asfixia.Algunos componentes tienen bordes afilados por razones funcionales.
G
Manéjelos con cuidado. G Este producto está pensado para ser utilizado únicamente en interiores.
recomendados por Hornby. G El transformador incluido no es un juguete: es un "transformador para juguetes".
no presenten daños. En caso de detectarse daños, no debe utilizarse la unidad Select hasta no sustituir el transformador por una nueva unidad recomendada por Hornby. Nunca intente abrir la unidad.
G Antes de limpiar cualquier pieza, desconecte el transformador de la red eléctrica.
salida de los transformadores no deben conectarse directa ni indirectamente a la salida de ninguna otra fuente de alimentación de la red.
Exclusiones
Con sujeción a las exclusiones que a continuación se exponen, el producto será reparado o sustituido gratuitamente si se determina que el problema detectado se debe a un defecto de materiales
o de mano de obra. La reparación o sustitución se realizará a la mayor brevedad para causar las mínimas molestias al cliente:
negligente o contrario a las recomendaciones del fabricante.
con su Oficina del Consumidor. Esta garantía cubre únicamente los productos fabricados por Hornby. Guarde esta información y la dirección para consultas futuras.
This Select Digital Control system is only to be operated with the Hornby recommended transformers.
G
Before use the transformer should be examined for damage to the casing, plug pins and cables. In the
G
Do not use liquid for cleaning. Wires without a connecting means are not to be
G G
Please retain
G
G The fault has been caused or is attributable to mis-use, negligent use or used contrary
Accidental physical damage.This guarantee is valid for products purchased in the United Kingdom and is in addition to, and does not
G
Ce produit est conçu pour être utilisé uniquement à l'intérieur. Ce système de commande numérique Select ne doit être utilisé qu'avec
G G
Le transformateur fourni n'est pas un jouet ; c'est un transformateur POUR jouets. Avant emploi, le transformateur devra être inspecté pour vérifier la
G
G Avant de nettoyer toute pièce, débranchez le transformateur de l'arrivée de courant de
G Ne branchez pas de fils sans raccord dans des prises. G Ne branchez pas directement ou indirectement les bornes de sortie des
G Veuillez conserver ces informations et cette adresse pour référence ultérieure.
La panne a été causée ou est attribuable à une utilisation à mauvais escient, négligente ou contraire aux conseils
G
Questo prodotto è destinato esclusivamente all'utilizzo in ambienti interni. Il sistema di comando digitale Select
G G
Il trasformatore in dotazione non è un giocattolo, si tratta di un trasformatore "per" giocattoli. Prima di utilizzare
G G
Prima di effettuare la pulizia di qualunque parte, scollegare il trasformatore dall'alimentazione della rete.
G
I terminali di uscita dei trasformatori non devono essere collegati né direttamente
G
E' consigliabile conservare le informazioni e gli indirizzi riportati in questo paragrafo per eventuali consultazioni future.
G
Il difetto è stato causato o va attribuito ad uso improprio, a negligenza o ad
G
Danni fisici accidentali. Per conoscere i Suoi diritti in qualità di consumatore riguardo a questo prodotto, La preghiamo di rivolgersi al Suo Centro
G
Dieses Produkt ist nur für die Verwendung im Innenraum vorgesehen. Diese Digitalsteuerung Select darf nur mit den von
G G
Der im Lieferumfang enthaltene Transformator ist kein Spielzeug, sondern vielmehr ein "Transformator für Spielzeuge". GVor derVerwendung
G
G Verwenden Sie zur Reinigung keine Flüssigkeiten. G Drähte ohne Steckverbinder dürfen nicht in die Steckdosen
G Bitte bewahren Sie diese Details
Der Fehler wurde durch unsachgemäße Handhabung, Nachlässigkeit
G
Versehentliche physikalische Beschädigung. Informationen zu Ihren
G
G Este sistema de control digital Select debe conectarse únicamente a los transformadores
G Antes de utilizar el transformador, verifique que la carcasa, el enchufe y los cables
G No utilice líquidos para la limpieza. G No conecte cables sin conector o pelados a ninguna toma. G Los terminales de
G Guarde esta información y la dirección para consultas futuras.
Si el problema ha sido causado o es atribuible a un uso indebido,
G
Si ha sufrido daños materiales accidentales. Si desea conocer sus derechos como consumidor en relación con este producto, consulte
G
Hornby Hobbies Limited, Margate, Kent CT9 4JX.
Tel: +44 (0) 1843 233525
4/1290
Non
G
G Vor der
Select Walkabout - Operators Instructions
