Scanstrut DECK POD Installationsanleitung Seite 3

Deck Pod
E
C
A
Max cut-out
F
B
area
45°
200
132
D
G
ø J
Deck Base Height
(SPD-7/7S dimensions
in square brackets)
95mm (3.7")
[67.5mm (1.73")]
Maximum
cut-out area
A B
mm / inches mm / inches mm / inches
SPD-7S-W
218/8.5 140.5/5.5 240/9.4
SPD-7-W
218/8.5 140.5/5.5 240/9.4
SPD-8-W
267/10.5 167/6.6 289/11.4
SPD-9-W
314/12.3 185/7.3 336/13.2
SPD-12-W
332.5/13 227/8.9 354.5/14
SPD-13-W
228/9.0 373/14.7
351/13.8
SPD-15D-W
423/16.7 333/13.1 424/16.7
SPD-4Xi-W
235/ 9.25 140/5.5 255/10.0
G H
mm / inches mm / inches mm / inches
SPD-7S-W
109/4.3 78/3.1 87/3.43
SPD-7-W 111/4.3 108/4.25 136/5.35
128.5/5.0 134/5.3 152.8/6.0
SPD-8-W
SPD-9-W 150/5.9 111/4.4 145/5.7
145/5.7
170/6.7 109/4.3
SPD-12-W
SPD-13-W 182/6.5 104/4.1 145/5.7
199/7.8 104/4.1
SPD-15D-W 146/5.7
SPD-4Xi-W 271/10.7 80/3.1 159/6.25
ø50mm (2.0")
[ø44 (1.73")]
Base Footprint
(SPD-7/7S dimensions in square
brackets)
Learn more about marine electronics and navigation on our website.
Maximum Overall
usable face dimensions
C D E F
mm / inches mm / inches mm / inches
159/6.25 275/10.8 196/7.7
159/6.25 275/10.8 196/7.7
190/7.5 324/12.75 228/8.97
207/8.14 374/14.7 243/9.56
244.5/9.6 392/15.5 286/11.3
246/9.7 409/16.1 287/11.3
349/13.7 482/19.0 396/15.6
160/6.3 565/22.25 192/7.5
I J M
K
mm / inches mm / inches
mm / inches
253/10.0
295/11.6 101/4.0
253/10.0
295/11.6 144/5.7
310/12.2
346/13.6 167/6.6
367/14.4
407/17.3 167/6.6
369/14.5
167/6.6
428/16.0
404/15.9
448/19.1 167/6.6
490/19.3
535/21.1 175/6.9
577/22.7 271.5/10.7 205/8.0
ø100mm (3.9")
[(ø81mm (3.2")]
ø85mm (3.3") PCD
[ø62.5mm (2.45")]
4x ø5mm
®
