1. Functional Overview
Front – fig. 1
Front cover
Red LED (behind the cover)
Transformer/Power supply plug
LED modes
• Permanent light
• No light
• Slow flashing
• Fast flashing
Back – fig. 2
Back plate
Front cover release
Back plate lock/unlock (turn 90°)
Screw hole for wall mounting
Screw and wall plug
Mounting with screws
Back plate
Screw hole for wall mounting
Screw and wall plug
Front Cover – fig. 3
Front cover release
Push Button – fig. 4
Push button (for installation/transmission test)
VI.UH.N5.1C

CF-RU Repeater Unit
ON
OFF
Flashes
Flickers
Produced by Danfoss Floor Heating Hydronics 03.2007
