INSTRUCTION MANUAL
Please read the manual before use. Before use, make sure the device is turned off. Nail drill battery indicator: full indicator – the
device is fully charged; blinking indicator – the device needs to be charged, the battery is low. The nail drill has a 2000 mAh
battery. The battery can be charged fully in 3.5 h. Fit the selected bit in the handpiece. Mind that it is properly set in its slot.
Connect the handpiece to the main body. For the handpiece to operate correctly, make sure you securely connected the plug of
the handpiece cable to the socket in the device. Turning the device on: press the On/Off button and hold for a second. Turning the
device off: press the On/Off button and hold for a second. Changing the rotation direction: the default direction is forward ("F");
you can switch it to reverse ("R") by pressing the button when the device is not running (i.e. the rotation speed is 0) To switch
back to the other direction, press the button again when the device is not running. The device will start running once the "0" ran-
ge on the knob is exceeded; increase the speed by turning the knob clockwise. Increase the speed by turning the knob towards
the "+" symbol, decrease it by turning the knob towards the "-" symbol. Speed range: 00–30. After you finish working with the
device, we recommend storing the handpiece with a bit or the blank bar inserted – this will protect the bit sleeve from damage.
DRILL BIT INSERTION INSTRUCTION
Turn the chuck's outer ring left so that the arrow lines up with the open lock symbol (until you hear a click), and insert the
Semilac bit in the handpiece in a way so that the distance between the edge of the handpiece and the lower edge of the bit head
is approx. 5–10 mm. This distance depends on the length of the shank of the bit and individual technique and preferences of the
operator. After securing it in the handpiece, the bit should not protrude too far, because this may cause the handpiece to vibrate
and make excessive noise. The bit should not be placed too deep in the handpiece either, as pushing it too far may damage the
handpiece mechanism. If, after you insert the bit in the sleeve, you feel resistance (which indicates that the bit has reached the
end of the sleeve), move it back out several millimetres. After inserting the bit in the sleeve, turn the chuck's outer ring right so
that the arrow lines up with the closed lock symbol (until you hear a click).
SPECIFICATIONS
Dimensions: 147x60x45 mm
Net weight: 0.56 kg
Rotational speed: RPM max 30 000
Input voltage: 5 VDC 2 A USB / 220 VAC, 50 Hz
Output voltage: 7,4 VDC 0,5 A
Power: 12W (max)
CHARACTERISTICS
• An easy bit fitting system
• Efficient and silent operation with no vibrations
• Speed is regulated with a knob
• Compact size
GENERAL INFORMATION AND WARNINGS
• Before use, make sure the bit is correctly fitted and secured in the handpiece. Starting the drill with a damaged or not
properly secured bit may cause damage to the device.
• Increase the speed gradually; do not turn the knob too abruptly.
• Do not touch the bits when the device is operating.
• Before changing the direction of rotation of the drill, reduce rotation speed to 0, and only then change the direction using
the switch.
• Do not cover the heat vents.
• Do not use the electric nail drill if the device or the cable are damaged.
• Correct and proper use in accordance with the guidelines will prolong the device's service life.
• Do not use the device when it is charging.
• The device is intended for use in enclosed spaces and should not be used outdoors.
WARRANTIES
• The warranty period is 24 months from the sale of the device to the first person purchasing it for use. The date of sale may
be determined according to a receipt, invoice, bill or any other document stating such date which the buyer is obligated to
produce.
• In the period covered by the warranty, we guarantee free exchange of the faulty device or repair of damage or faults of the
device resulting from manufacturing defects upon delivery of the faulty device to the point of sale. For devices purchased
online at www.semilac.eu, the address for delivering the faulty device is: Nesperta sp. z o.o., ul. Poznańska 165, 62-052
Komorniki.
