8 SMS PRESENCE MOBILE/FLOOR SPEED
1
SMS Presence
Speed Floor
(use outer holes)
1a
Mark holes (4x)
1c
Bolt stand to floor
Use suitable screws
for PRESENCE FLOOR SPEED only
Bolt floor stand to floor
Holes pattern
25,79
655 SMS Presence Speed Floor All
1b
Drill holes (4x)
Min 70 mm
Min 70 mm
