INSTALLATION

Ceiling Mounting

1� Use the mounting template to drill the necessary holes in the correct position in
the ceiling�
2� Hammer the four expansion crews into the holes�
3� Feed the power and BNC cables through the box�
4� Secure the box with the four screws�
5� Insert the sealing ring into the bracket to seal it�
6� Tighten the box cover with the four screws on the bottom of the box�
7� Connect the power and BNC cables to the camera cables�
8� Adjust the angle of view of the camera�
9� Attach the camera mount to the housing cover�

Wall Mounting

1� Use the drilling template to drill the necessary holes in the correct position in the
wall�
2� Then mount the box on the wall by following steps 2-9 for ceiling mounting�
