- Seite 1 All manuals and user guides at all-guides.com KOP2555-XHB, KOP2555-S-XHB 46" - 55" 150 lb (117 - 140 cm) (68 kg) ČEŠ TÜR 2018-08-15 #:150-9100-2 (2018-10-10)
- Seite 2 All manuals and user guides at all-guides.com WARNING ENG - Before installing make sure the supporting surface will support the combined load of the equipment and hardware. Screws must be tightly secured. Do not overtighten screws or damage can occur and product may fail.
- Seite 3 All manuals and user guides at all-guides.com WAARSCHUWING NEL - Vóór de installatie dient u zich ervan te overtuigen dat het dragende oppervlak het totaalgewicht van de apparatuur en de hardware aankan. Alle schroeven moeten stevig vastzitten. Draai de schroeven niet te strak aan, want dit zou kunnen resulteren in schade en/of falen van het product.
- Seite 4 All manuals and user guides at all-guides.com AVISO POR - Antes de instalar, certifique-se de que a superfície de apoio suporta a carga combinado do equipamento e das ferragens. Os parafusos devem ser bem apertados. Não aperte demasiado os parafusos, pois podem ocor- rer danos ou falhas do produto.
- Seite 5 All manuals and user guides at all-guides.com This page intentionally left blank. Página en blanco. Cette page a été laissée en blanc intentionnellement. Diese Seite wurde absichtlich freigelassen. Deze pagina is met opzet blanco gelaten. Pagina lasciata intenzionalmente vuota. Tato strana je záměrně prázdná. ČEŠ...
- Seite 6 All manuals and user guides at all-guides.com Symbols Símbolos Symboles Symbole Symbolen WARNING Simboli ADVERTENCIA ČEŠ Symboly ADVERTISSEMENT Symboly ACHTUNG Screws must get at least three Símbolos WAARSCHUWING full turns and fit snug. Semboller TÜR AVVERTENZA Los tornillos tienen que dar, ČEŠ...
- Seite 7 All manuals and user guides at all-guides.com Tools Needed for Assembly. Herramientas necesarias para el ensamblaje. Outils nécessaires au montage. To properly tighten screws: Tighten until screw Für den Zusammenbau erforderliche Werkzeuge. head makes contact, then tighten another 1/2 Voor montage benodigd gereedschap. turn.
- Seite 8 Diely (predtým, ako začnete, pripravte si všetky diely zobrazené nižšie). Peças (antes de iniciar, certifique-se de que tem todas as peças apresentadas em baixo). Parçalar (Başlamadan önce, aşağıda gösterilen bütün parçaların elinizde olduğundan emin olun). TÜR Parts List KOP2555-XHB KOP2555-S-XHB Description Part# Part#...
- Seite 9 All manuals and user guides at all-guides.com This page intentionally left blank. Página en blanco. Cette page a été laissée en blanc intentionnellement. Diese Seite wurde absichtlich freigelassen. Deze pagina is met opzet blanco gelaten. Pagina lasciata intenzionalmente vuota. Tato strana je záměrně prázdná. ČEŠ...
- Seite 10 All manuals and user guides at all-guides.com Remove quite retirez entfernen verwijderen rimuovere odstranit ČEŠ odstrániť remova çıkartın TÜR 2018-08-15 #:150-9100-2 (2018-10-10)
- Seite 11 All manuals and user guides at all-guides.com Remove quite retirez entfernen verwijderen rimuovere odstranit ČEŠ odstrániť remova çıkartın TÜR 2018-08-15 #:150-9100-2 (2018-10-10)
- Seite 12 All manuals and user guides at all-guides.com WARNING ENG - When installing Peerless mounts to threaded rods, the rods must be 1/2" diameter minimum, 70 KSI tensil strength. The hardware must be installed and supported per the manufacturer's design specifications. Use only compatible hardware.
- Seite 13 All manuals and user guides at all-guides.com UYARI TUR - Peerless askı aparatlarını çelik cıvatalarla monte ederken, cıvataların çapının asgari 1/2” (13mm) ve çekme mukavemetinin 70 KSI olması gerekir. Donanımın üreticinin tasarım özelliklerine göre monte edilmesi ve desteklenmesi gerekir. Sadece uyumlu donanım kullanın. Asla çelik cıvataların veya destek yüzeyinin azami yük kapasitesini aşmayın.
- Seite 14 All manuals and user guides at all-guides.com Remove quite 3/4" retirez (19mm) entfernen verwijderen rimuovere odstranit ČEŠ odstrániť remova çıkartın TÜR Adjust Ajuste Réglez Einstellen Aanpassen Regolare Nastavit ČEŠ Nastaviť Ajuste Ayarlayın TÜR 2018-08-15 #:150-9100-2 (2018-10-10)
- Seite 15 All manuals and user guides at all-guides.com 3/4" (19mm) Stainless steel 1/2" hex nut (not included). Tuerca hexagonal de 1/2“ de acero inoxidable (no incluidos). Écrou hexagonal de 1/2 po (13mm) en acier inoxydable (non compris). 1/2 Zoll-Edelstahl-Sechskantmutter, p. Zoll (nicht inbegriffen).
- Seite 16 All manuals and user guides at all-guides.com Unlock Destrabe Déverrouiller Entriegeln Ontgrendelen Sblocca Odemknout ČEŠ Odomknúť Desbloquear Kilidi açın TÜR 2018-08-15 #:150-9100-2 (2018-10-10)
- Seite 17 All manuals and user guides at all-guides.com Remove quite retirez entfernen verwijderen rimuovere ČEŠ odstranit odstrániť remova çıkartın TÜR 2018-08-15 #:150-9100-2 (2018-10-10)
- Seite 18 All manuals and user guides at all-guides.com 1/2" (13mm) Remove Loosen. quite Afloje. retirez Desserrez. entfernen Lösen. verwijderen Losdraaien. rimuovere Allentare. ČEŠ odstranit ČEŠ Uvolnit. odstrániť Uvoľniť. remova Desaperte. çıkartın Gevşetin. TÜR TÜR 2018-08-15 #:150-9100-2 (2018-10-10)
- Seite 19 All manuals and user guides at all-guides.com Remove quite retirez entfernen verwijderen rimuovere odstranit ČEŠ odstrániť remova çıkartın TÜR 2018-08-15 #:150-9100-2 (2018-10-10)
- Seite 20 All manuals and user guides at all-guides.com Remove quite retirez entfernen verwijderen rimuovere odstranit ČEŠ odstrániť remova çıkartın TÜR Replace Remplace Remettez en place Ersetzen Vervangen Rimettere a posto Znova nasadit ČEŠ Znova nasadiť Coloque novamente Değiştirin TÜR Maximum 36 in. • lb (4 N.M.). Máxima 36 in.
- Seite 21 All manuals and user guides at all-guides.com 2018-08-15 #:150-9100-2 (2018-10-10)
- Seite 22 All manuals and user guides at all-guides.com Replace Remplace 1/2" Remettez en place (13mm) Ersetzen Vervangen Rimettere a posto Znova nasadit ČEŠ Znova nasadiť Coloque novamente Değiştirin TÜR 2018-08-15 #:150-9100-2 (2018-10-10)
- Seite 23 All manuals and user guides at all-guides.com 1/2" (13mm) Tighten. Apretar. Serrer. Anziehen. Aandraaien. Stringere. Utáhněte. ČEŠ Utiahnite. Apertar. Sıkmak. TÜR 2018-08-15 #:150-9100-2 (2018-10-10)
- Seite 24 All manuals and user guides at all-guides.com Unlock Destrabe Déverrouiller Entriegeln Ontgrendelen Sblocca Odemknout ČEŠ Odomknúť Desbloquear Kilidi açın TÜR 2018-08-15 #:150-9100-2 (2018-10-10)
- Seite 25 All manuals and user guides at all-guides.com Cable management manejo de cables gestion des câbles Kabelführung kabelbeheer gestione dei cavi vedení kabelů ČEŠ vedenie káblov gestão de cabos kablo yönetimi TÜR 2018-08-15 #:150-9100-2 (2018-10-10)
- Seite 26 All manuals and user guides at all-guides.com Optional. Opcional. Facultatif. Fakultativ. Facultatief. Opzionale. Volitelné. ČEŠ Voliteľné. Opcional. İsteğe bağli. TÜR Remove quite retirez entfernen verwijderen rimuovere odstranit ČEŠ odstrániť remova çıkartın TÜR Cable management manejo de cables gestion des câbles Kabelführung kabelbeheer gestione dei cavi...
- Seite 27 All manuals and user guides at all-guides.com Lock Trabe Verrouillez Arretieren Vergrendelen Bloccare Zajistit ČEŠ Zaistiť Bloqueie Kilitleyin TÜR 2018-08-15 #:150-9100-2 (2018-10-10)
- Seite 28 All manuals and user guides at all-guides.com 10-1 Replace Remplace Remettez en place Ersetzen Vervangen Rimettere a posto ČEŠ Znova nasadit Znova nasadiť Coloque novamente Değiştirin TÜR 2018-08-15 #:150-9100-2 (2018-10-10)
- Seite 29 All manuals and user guides at all-guides.com 10-2 Lock Trabe Verrouillez Arretieren Vergrendelen Bloccare Zajistit ČEŠ Zaistiť Bloqueie Kilitleyin TÜR 2018-08-15 #:150-9100-2 (2018-10-10)
- Seite 30 All manuals and user guides at all-guides.com 11-1 Replace Remplace Remettez en place Ersetzen Vervangen Rimettere a posto Znova nasadit ČEŠ Znova nasadiť Coloque novamente Değiştirin TÜR 2018-08-15 #:150-9100-2 (2018-10-10)
- Seite 31 All manuals and user guides at all-guides.com 11-2 Replace Remplace Remettez en place Ersetzen Vervangen Rimettere a posto ČEŠ Znova nasadit Znova nasadiť Coloque novamente Değiştirin TÜR 2018-08-15 #:150-9100-2 (2018-10-10)
- Seite 32 All manuals and user guides at all-guides.com This page intentionally left blank. Página en blanco. Cette page a été laissée en blanc intentionnellement. Diese Seite wurde absichtlich freigelassen. Deze pagina is met opzet blanco gelaten. Pagina lasciata intenzionalmente vuota. Tato strana je záměrně prázdná. ČEŠ...
- Seite 33 (from date of the original installation of the product). At its option, Peerless-AV will repair or replace, or refund the purchase price of, any product which fails to conform with this warranty.
- Seite 34 (dalla data dell’installazione originale del prodotto). A sua discrezione, Peerless-AV sostituirà o riparerà, o restituirà il prezzo pagato se il prodotto non è conforme a questa garanzia.
- Seite 35 (a partir da data da primeira instalação do produto). A seu critério, a Peerless-AV reparará ou substituirá (ou reembolsará o preço de compra de) qualquer produto que não esteja em conformidade com esta garantia.
- Seite 36 All manuals and user guides at all-guides.com Peerless-AV Peerless-AV Europe Peerless-AV de Mexico 2300 White Oak Circle Unit 3 Watford Interchange, Ave de las Industrias 413 Aurora, IL 60502 Colonial Way, Watford, Herts, Parque Industrial Escobedo Email: tech@peerlessmounts.com WD24 4WP, United Kingdom Escobedo N.L Mexico 66062...
