INSTALLATION AND
ADJUSTMENT MANUAL
M000307
ENX1025 Evoko Naso Freestand
DE Handbuch für Installation und Anpassung
IT Manuale per l'installazione e la regolazione
ES Manual de instalación y ajuste
FI Asennus- ja säätöohje
FR Manuel d'installation et de réglage
NL Handboek voor installatie en instellingen
PL
RUS
ARB
SE Monterings- och justeringsmanual
GR
Werbung
Verwandte Anleitungen für EVOKO M000307
Inhaltszusammenfassung für EVOKO M000307
- Seite 1 INSTALLATION AND ADJUSTMENT MANUAL M000307 ENX1025 Evoko Naso Freestand DE Handbuch für Installation und Anpassung IT Manuale per l'installazione e la regolazione ES Manual de instalación y ajuste FI Asennus- ja säätöohje FR Manuel d’installation et de réglage NL Handboek voor installatie en instellingen...
- Seite 2 2 EVOKO NASO FREESTAND GB – Instructions for Mounting IT – Istruzioni per il montaggio Warning Avvertenze A correct mounting is extremely important and this is not the responsibility of Un montaggio corretto è della massima importanza e non è responsabilità di AB.
- Seite 3 Sulla ricevuta devono essere chiaramente leggibili nome be clearly legible on the receipt. The owner is to pay the cost of returning the product to Evoko, while del fornitore e data d’acquisto. Le spese di spedizione a Evoko sono a carico dell’acquirente;...
- Seite 4 EVOKO NASO FREESTAND ASSEMBLY INSTRUCTIONS YOU WILL NEED Allen key Nos. 3, 6 NOT INCLUDED Display - Naso NUMBER OF PERSONS REQUIRED...
-
Seite 5: List Of Parts
EVOKO NASO FREESTAND LIST OF PARTS (1x) (1x) (1x) (4x) (4x) plastic cap M10x30 (4x) (4x) M5x20 M4x8 [DIN 7991] [ISO 7045]... - Seite 6 6 EVOKO NASO FREESTAND Prepare base - mount feet B2(4x) (4x) Tighten all B2(4x)
- Seite 7 EVOKO NASO FREESTAND Mount pillar on base S1(4x) (4x) Attach plastic caps B3(4x) (4x)
- Seite 8 8 EVOKO NASO FREESTAND Mount Naso* bracket stand Slide Adjust tilt ( Min.0° - Max.30°) Tighten *Liso display also compatible...
- Seite 9 EVOKO NASO FREESTAND Mount Naso* plastic base (included with Naso* unit) S2 (4x) Refer display manual *Liso display also (4x) compatible...
- Seite 10 10 EVOKO NASO FREESTAND Guide all cables...
- Seite 11 EVOKO NASO FREESTAND Attach cables to Naso* unit Position Naso* unit on plastic base Twist clockwise to lock unit on base Refer display manual Refer main manual for guidance on installation *Liso display also compatible of display to wall bracket...
-
Seite 12: Product Dimensions
12 EVOKO NASO FREESTAND PRODUCT DIMENSIONS 5,20 5,91 SECTION A-A 7,68 11,81 11,81 All dimensions in mm. Dimensions in [brackets] are in inches. SMS Smart Media Solutions AB Hästholmsvägen 32, 5th floor, SE-131 30 Nacka, Sweden www.smartmediasolutions.se...
