Programs 21 to 99
After having selected a program from 21 to 99, press key
Intensity control
By "intensity" we mean the value of current emitted to the body part and thus the degree of stimulation
causing the muscle to contract. Symbol
adjust the intensity using keys
at the same time. When you set the intensity, the clock begins to flash indicating that the equipment is
providing energy (fig. 14 page 68). You can, however, access each channel during use to control the
intensity independently: simply press key
and then use keys
intensity values for the 4 channels can be different.
The display constantly updates the treatment time until completion, as well as showing all the set
parameters, meaning that you can always control the treatment.
At the end of the treatment, the Tesmed Max 7.8 clears the intensity setting for all output channels. You can
now switch the equipment off by pressing key
treatment. Use keys
Keep pressed for faster increases/decreases.
NB: To perceive a change in intensity in a single channel or all channels, changes are only made when the
muscle is contracting. This avoids the risk of uncontrolled or sudden changes in intensity. During the
treatment you can quickly clear the intensity setting by pressing key
settings are restored and so you can start increasing/decreasing the intensity again to resume the
treatment.
Frequency control (for programs 01 to 20)
Programs 01 to 20 let you correct the pulse frequency value at will. The "frequency" is the number of pulses
per second. When you change the frequency, you feel an increase or decrease in the speed of stimulation.
These programs are identified by a special symbol
After starting the treatment, press key
and
repeatedly to increase or to decrease the frequency. The symbol
speed) to indicate frequency control mode. Press key
NB: if in frequency control mode during a treatment and you want to clear the intensity, briefly press key
twice. All the default parameter settings are restored and so you can start increasing/decreasing the
MODE
MODE
intensity again to resume the treatment.
Error warning
The Tesmed Max 7.8 automatically goes into error mode if an electrode comes loose. In this case, the
equipment display will show "er" (flashing for about 5 seconds) against the channel with the current
distribution problem (fig. 17 page 68). All pulses are stopped immediately and "00" appears as the
insensity value on the display. The error message can mean that:
• There are no electrodes connected to the channel in error mode.
• The electrodes are not properly adhered to the skin: reposition the electrodes or replace if too old.
• The cable used to connect the electrodes is faulty: check by inverting two cables.
and
(1÷99). The intensity rises or falls on all the selected channels
and
to increase or decrease the value. Fig. 15 page 68 shows that the
and
, to increase or decrease the value of any parameter (in steps of one unit).
for 3 seconds to enter the frequency control mode. Press keys
MODE
MODE
to go straight to the intensity control.
MODE
MODE
appears on the display (fig. 13 page 68): you can now
to select the channel whose intensity you want to change
for 2 seconds or set new parameters to begin a new
MODE
MODE
on the display (fig. 16 page 68).
once to quit frequency control mode.
MODE
MODE
- 26 -
- 26 -
. briefly. All the default parameter
flashes (at a varying
