PORTAVALIGIE LATERALE SPECIFICO - SPECIFIC TUBULAR SIDE-CASE HOLDER - PORTE-VALISES LATÉRAUX SPÉCIFIQUE
SPEZIFISCHES STAHLROHR-SEITENTRAEGER - PORTA MALETAS LATERALES ESPECÍFICO - SUPORTE DE MALAS ESPECÍFICO
N°
Descrizione/Description
Telaio laterale - Side frame - Châssis latéral
1
Soporte lateral - Seitenrahmen - Suporte lateral
Ponte - Bridge - Pont
2
Brücke - Puente – Ponte
Supporto anteriore - Front support -Support avant
3
Vordere Unterstützung - Soporte frontal - Suporte frontal
Supporto Frecce - Indicators support - Support clignotants
4
Blinkerhalterung - Soporte para los indicadores - Suporte para
Piastrina di rinforzo - Strengthening plate
5
Plaque de renfort - Verstärkungsplatte
Pletina de refuerzo - Placa de reforço
Piastrina di rinforzo - Strengthening plate
6
Plaque de renfort - Verstärkungsplatte
Pletina de refuerzo - Placa de reforço
Vite - Screw - Vis - Schraube
7
Vite - Screw - Vis - Schraube
8
Vite - Screw - Vis - Schraube
9
Vite - Screw - Vis - Schraube
10
Vite - Screw - Vis - Schraube
11
Rondella spaccata - Split washer
12
Scheibe - Rondelle fendue
Arandela seccionada - Arruela Dentada
Rondella - Washer - Rondelle - Scheibe
13
Arandela – Arruela
Distanziale - Spacer - Entretoise - Distanzstueck
14
Distanciador – Espaçado
Distanziale - Spacer - Entretoise - Distanzstueck
15
Distanciador – Espaçado
Distanziale - Spacer - Entretoise - Distanzstueck
16
Distanciador – Espaçado
Distanziale - Spacer - Entretoise - Distanzstueck
17
Distanciador – Espaçado
Dado - Bolt - Ecrou
18
Mutter - Tuerca – Porca
Dado - Bolt - Ecrou
19
Mutter - Tuerca – Porca
Dado - Bolt - Ecrou
20
Mutter - Tuerca – Porca
Tappo - Cap - Fiche - Stecker
21
©Copyright 5/06/2023 LF-Rev00
PLO1201CAM - KLO1201CAM
HONDA XL 750 TRANSALP (2023)
indicadores
Tornillo - Parafuso
Tornillo - Parafuso
Tornillo - Parafuso
Tornillo - Parafuso
Tornillo - Parafuso
Enchufe – Capa
ISTRUZIONI DI MONTAGGIO - MOUNTING INSTRUCTIONS
INSTRUCTIONS DE MONTAGE - BAUANLEITUNG
INSTRUCCIONES DE MONTAJE - INSTRUÇÕES DE MONTAGEM
Caratteristiche/Features
-
-
-
-
INOX
-
TBEI M8x70
TBEI M8x110
TBEI M8x25
TBEIFL M6x20
TSP M6x25
Foro Ø8mm
Foro Ø8mm Esterno Ø20mm Sp.2mm
Ø20x7,5 Foro 8,5mm
Ø18x16 Foro 8,5mm
Ø16x4 Foro 8,5mm
Ø14x9 Foro 8,5mm
Dado Autobloccante Flangiato
M8 ( H.9,5mm)
Dado Autobloccante Flangiato
Alto M6 ( H.9mm)
Dado Autobloccante Flangiato
Basso M6 ( H.7mm)
-
Codice/Code
Quantità/quantity
PLO1201CAMDXV
2 (Right: Left)
PLO1201CAMSXV
1
GL5562V
GL5559DXV
2 (Right: Left)
GL5559SXV
2 (Right: Left)
GL5563V
2
GL5564G
2
GL5565V
2
870TBEI
2
8110TBEI
4
825TBEI
4
620TBEIFL
2
625TSP
4
Z1060
12
820RON
2
C20L7,5F8,5T
2
C18L16F8,5T
1
C16L4F8,5T
1
C14L9F8,5T
4
8DADIFN
2
6DADIAFLN
4
6DADIABFN
4
13COP
1/14
