PORTAVALIGIE LATERALE SPECIFICO - SPECIFIC TUBULAR SIDE-CASE HOLDER - PORTE-VALISES LATÉRAUX SPÉCIFIQUE
SPEZIFISCHES STAHLROHR-SEITENTRAEGER - PORTA MALETAS LATERALES ESPECÍFICO - SUPORTE DE MALAS ESPECÍFICO
N°
Descrizione/Description
Telaio laterale - Side frame - Châssis latéral
1
Soporte lateral - Seitenrahmen - Suporte lateral
Ponte - Bridge - Pont
2
Brücke - Puente – Ponte
Supporto inferiore - Lower support - Support inférieur
3
Soporte inferior - Untere Halterung - Suporte inferior
Supporto superiore - Support higher - Support supérieur
4
Halterung höher - Soporte superior - Apoio superior
Vite - Screw - Vis - Schraube
5
Tornillo - Parafuso
Vite - Screw - Vis - Schraube
6
Tornillo - Parafuso
Vite - Screw - Vis - Schraube
7
Tornillo - Parafuso
Vite - Screw - Vis - Schraube
8
Tornillo - Parafuso
Vite - Screw - Vis - Schraube
9
Tornillo - Parafuso
Rondella - Washer - Rondelle - Scheibe
10
Arandela – Arruela
Rondella - Washer - Rondelle - Scheibe
11
Arandela – Arruela
Rondella spaccata - Split washer - Scheibe - Rondelle fendue
12
Arandela seccionada - Arruela Dentada
Rondella - Washer - Rondelle - Scheibe
13
Arandela – Arruela
Distanziale - Spacer - Entretoise - Distanzstueck
14
Distanciador - Espaçador
Dado - Bolt - Ecrou
15
Mutter - Tuerca – Porca
Tappo - Cap - Fiche - Stecker
16
Protezione Adesiva - Adhesive Protection
17
Protection Adhesive - Schutzkleber
Protección Adhesiva - Proteção Adesiva
Boccola - Mounting bush
18
Entretoise de montage -Cilindro de fi jación
Montagehülse - Bucha de fi xação
Componenti Originali - Original Parts
19
Parties Originales - Original Bauteile
Componentes Originales - Componentes Originais
Particolari Inclusi nel SRA8400
Components Included In The SRA8400
Pièces Inclues Dans SRA8400
20
Die Einzelnen Teile Sind Bei SRA8400
Despieces Incluidos SRA8400
Componentes inclusos na SRA8400
Particolari Inclusi nel 08RKIT
Components Included In The 08RKIT
Pièces Inclues Dans 08RKIT
21
Die Einzelnen Teile Sind Bei 08RKIT
Despieces Incluidos 08RKIT
Componentes inclusos na 08RKIT
©Copyright 28/07/2021 LF-Rev01
PLO8400MK - KLO8400MK
HARLEY DAVIDSON PAN AMERICA 1250 (2021)
Enchufe – Capa
ISTRUZIONI DI MONTAGGIO - MOUNTING INSTRUCTIONS
INSTRUCTIONS DE MONTAGE - BAUANLEITUNG
INSTRUCCIONES DE MONTAJE - INSTRUÇÕES DE MONTAGEM
Caratteristiche/Features
-
-
-
-
TCE M8x30
TBEI M8x60
TBEI M8x55
TBEI M8x80
TBEI M8x25
Foro Ø8mm
Foro Ø8mm Esterno Ø24/25mm Sp.2/3mm
Foro Ø8mm
Foro Ø8mm Esterno Ø20mm Sp.2mm
Ø20x6,2 Foro 8,5mm
Dado Autobloccante Flangiato
M8 ( H.9,5mm)
-
-
-
-
-
-
Codice/Code
Quantità/quantity
PLO8400MKDXV
2 (Right: Left)
PLO8400MKSXV
GNB2773V
1
GL4881DXV
2 (Right: Left)
GL4881SXV
GL4880V
2
830TCE
4
860TBEI
2
855TBEI
2
880TBEI
2
825TBEI
4
8RON
4
258RON
2
Z1060
4
820RON
16
C20L6,2F8,5T
2
8DADIFN
6
13COP
6
Z298
4
Z4039
4
-
-
-
-
-
-
1/10
