Data Page of infraNOMIC Heating Panels

Framed heaters - black, white, mirror
Size w x h
23,62 x 15,75 inch (600 x 400 mm)
35,43 x 13,78 inch (900 x 350 mm)
27,56 x 23,62 inch (700 x 600 mm)
35,43 x 23,62 inch (900 x 600 mm)
43,31 x 23,62 inch (1100 x 600 mm)
47,24 x 13,78 inch (1200 x 350 mm)
47,24 x 23,62 inch (1200 x 600 mm)
51,18 x 15,75 inch (1300 x 400 mm)
55,12 x 23,62 inch (1400 x 600 mm)
Frameless heaters - black, white, mirror
Size w x h
35,43 x 13,78 inch (900 x 350 mm)
27,56 x 23,62 inch (700 x 600 mm)
35,43 x 23,62 inch (900 x 600 mm)
43,31 x 23,62 inch (1100 x 600 mm)
47,24 x 13,78 inch (1200 x 350 mm)
47,24 x 23,62 inch (1200 x 600 mm)
51,18 x 15,75 inch (1300 x 400 mm)
55,12 x 23,62 inch (1400 x 600 mm)
Metall – Heizelemente rahmenlos, pulverbeschichtet RAL9016 (Steel-Line)
Model
Size
600 x 600 mm MHE-66
625 x 625 mm MHE-6262
700 x 600 mm MHE-76
900 x 600 mm MHE-96
1100 x 600 mm MHE-116
1200 x 600 mm MHE-126
* Due to the nature of tempered safety-glass variations of planity may occur.
** These values serve as a rough orientation for a building with modern heat insulation.
*** Due to the surface temperatures of approx. 110° C only for ceiling mounting.
*, picture
Model Power
l Watt
GHE-64-M 210
GHE-93-M 270
GHE-76-M 400
GHE-96-M 530
GHE-116-M 630
GHE-123-M 350
GHE-126-M 700
GHE-134-M 500
GHE-146-M 900
*, picture
Model Power
Watt
GHE-93-SL 270
GHE-76-SL 400
GHE-96-SL 530
GHE-116-SL 630
GHE-123-SL 350
GHE-126-SL 700
GHE-134-SL 500
GHE-146-SL 900
Size of room to be
Power
heated
Watt approx. m²**
350 6-7
350 6-7
400 7-8
500 11-12
600 13-14
700 16-18
Size of room to be heated
approx.**
21-32 ft² (2-3 m²)
32-43 ft² (3-4 m²)
75-86 ft ² (7-8 m²)
118-129 ft² (11-12 m²)
140-150 ft² (13-14 m²)
75-86 ft ² (7-8 m²)
172-193 ft² (16-18 m²)
118-129 ft² (11-12 m²)
215-236 ft² (20-22 m²)
Size of room to be heated
approx. **
32-43 ft² (3-4 m²)
75-86 ft ² (7-8 m²)
118-129 ft² (11-12 m²)
140-150 ft² (13-14 m²)
75-86 ft ² (7-8 m²)
172-193 ft² (16-18 m²)
118-129 ft² (11-12 m²)
215-236 ft² (20-22 m²)
Frameless MHE
Frameless MHE
Wall/ceiling
Weight
-
-
7 kg
10 kg
12 kg
13 kg
Aluminium Frame
10/23/33 mm-X
Weight approx.
11 lb (5 kg)
11 lb (5 kg)
15,4 lb (7 kg)
22 lb (10 kg)
26,5 lb (12 kg)
15,4 lb (7 kg)
28,6 lb (13 kg)
22 lb (10 kg)
30,8 lb (14 kg)
Frameless SL
Metal Backing-X
Weight
13,2 lb (6 kg)
17,6 lb (8 kg)
24,2 lb (11 kg)
28,6 lb (13 kg)
17,6 lb (8 kg)
30,8 lb (14 kg)
24,2 lb (11 kg)
33 lb (15 kg)
***
Ceiling only
Weight
6 kg
7 kg
-
-
-
-
20
