Oberon DL
User manual
Thank you for purchasing the Lightpro Oberon DL.
This document contains the required information for
correct, efficient and safe use of the product. Consult the
user manual of your transformer for more information
about the installation and connection of your lighting
plan or visit our website www.lightpro.nl
Read the information in this manual carefully before
using the product. Keep this manual near the product for
consultation in the future.
PRODUCT DESCRIPTION
The Lightpro Oberon is a standing LED lamp for outdoor
use. The fixture can be mounted on a solid surface
or placed in the ground with the supplied spikes.
This product may only be used as outdoor lighting in
combination with the Lightpro 12-volt system. Any
alterations made to the product may have consequences
for the safety, guarantee and correct functioning of the
product and/or other parts of the system.
SPECIFICATIONS
Product
Article number
Light source
Power (max.)
Luminous flux (max)
Light colour
Dimensions (H x D x W)
Protection class
Ambient temperature
Cable length
Dimmable
Light source
PACKAGING CONTENT
[Figure A]
1. Oberon DL fixture
2. Ground spike
3. Screws
4. Screws
5. Plugs
6. Lightpro F-connector
7. Hex key
8. Insert template for light angle
Check if all parts are present in the packaging.
For questions about parts, service, and any complaints or
other remarks, you can always contact us.
E-mail: info@lightpro.nl
Lightpro Oberon DL
192P
LED 9W AC/DC 12V
9W
750 lm
3.000K
600 x 110 x 63 mm
IP44
-20°C to 50°C
1m
Yes. Adjustable to 6 levels
Not replaceable
INSTALLATION
OPTION 1: INSTALLATION IN THE GROUND.
[Figure B]
Secure the spike [2] to the base [9] with the supplied
screws [3] using the hex key provided [7].
OPTION 2: INSTALLATION ON SOLID GROUND
[Figure C, D, E]
1. Remove the screw [11] from the fixture [1] using the hex
key provided [7].
2. Turn the base [9] anti-clockwise, as far as it will go.
Then, remove the base.
3. Secure the base [9] to the ground using the screws [4].
4. Place the fixture [1] onto the base [9].
5. Turn the fixture clockwise (seen from above), as far as
it will go.
6. Using the hex key [7], secure the screw [11] to the fixture
[1] and base [9].
NB: Pre-drill holes if necessary and use the plugs
provided [5].
SETTING THE DIMMER
The Oberon DL comes with a dimmer that can be set to
6 different pre-programmed levels.
[Figure F, G]
1. Turn the lamp holder [10] clockwise (seen from above),
as far as it will go.
2. Then, carefully pull the lamp holder [10] out of the
fixture using a gentle twisting motion.
3. Set the desired brightness using the push button. Light
can be set to six levels.
NB: Thanks to the memory function, the dimmer will
retain the set level when the light is switched off.
retain the set level.
4. Install the lamp holder [10] into the fixture, in reverse
order.
5. Check that the lamp holder is in the correct position.
SETTING THE LIGHT PATTERN
With the Oberon DL, you can change the light angle using
three different insert templates [8], which are included
as standard.
[Figure H, I]
1. Choose the desired plate [8].
2. Insert the template [8] into the corresponding slot in
the lamp holder.
3. Press the template into the correct position manually,
until it clicks in place.
4. To change the template, simply remove the current
plate manually and replace it with the desired template.
