Agate
User manual
Thank you for purchasing the Lightpro Agate.
This document contains the required information for
correct, efficient and safe use of the product. Consult the
user manual of your transformer for more information
about the installation and connection of your lighting
plan or visit our website www.lightpro.nl
Read the information in this manual carefully before
using the product. Keep this manual near the product for
consultation in the future.
PRODUCT DESCRIPTION
The Lightpro Agate is an LED spot for outdoor use. The
fixture can be installed in a fixed underground.
This product may only be used as outdoor lighting in
combination with the Lightpro 12-volt system. Any
alterations made to the product may have consequences
for the safety, guarantee, and correct
functioning of the product and/or other parts of the
system.
SPECIFICATIONS
Product
Article number
Light source
Power (max)
Luminous flux (max)
Light colour
Average lifetime
Dimensions (H x Ø)
Protection class
Ambient temperature
Cable length
Dimmable
Light source
PACKAGING CONTENT
[Figure A]
1 Fixture Agate
2 Tube
3 Hex key
4 Lightpro connector 137a
Lightpro Agate
102U
MR16 Led GU5.3 3W AC/DC 12V
3W
230 lm
3.000K
25.000
113 x 90 mm
IP67
-20 °C to 50 °C
0,5m
No
Replaceable
Check if all parts are present in the packaging. For
questions about parts, service, and any complaints or
other remarks, you can always contact us.
E-mail: info@lightpro.nl.
INSTALLATION
[Figure B]
1. Install the products in the desired position and lay the
cables so that they can be comfortably connected to
the transformer or cables.
2. If products are provided with a drain hole for water, this
hole must be pointing downwards.
3. Use non-corrosive fixing materials (supplied as
standard) if you want to bolt the products down.
4. Connect the lights to the main cable by using the
connector as shown on page 5.
5. Plug the plug of the transformer into the wall socket
(230 Volt 50 Hz).
REPLACEABLE LIGHTSOURCE
[Figure C]
Proceed as follows in order to install or change the light
source:
1. Turn the power off.
2. Let the light source cool down for at least 5 minutes.
3. Replace the light source, bearing the following points
in mind:
• Only replace the light source by an identical model
with the same specifications.
• When (re)assembling, ensure that the parts are dry
and clean.
4. Turn the power back on.
Proceed as follows if the lamps do not light after you
have followed the above instructions:
1. Turn the power off.
2. Check whether all plugs have been connected properly.
3. Check the light source(s) and replace them if necessary.
4. Check the transformer and the fuse (if applicable, and
have them circuit-tested if necessary).
5. Check whether cables have been damaged.
6. Turn the power back on.
Note: The rubber ring must be completely clean before
replacing the glass because of the water resistance.
