Preparing for use

Inserting/removing accessories
(Figure 2)
Before releasing the accessories, switch
1
off the mixer and remove the plug
from the mains socket!
0 Push the whisks or dough hooks into
the accessory slots on the underside of
the mixers, until they click into place.
1 The two dough hooks have different
plug shapes and must be pushed into
the correct slots. Insertion the wrong
way round would lead to the dough
being transported upwards!
0 One of the dough hooks has an
additional small ring near the collar
on the shaft. This dough hook will
only fit in the slot for which it
is intended. This is identified by a
symbol.
0 To remove the accessories, hold firmly
with one hand, while pressing the
accessory release button (Figure 1/A).

Working with the mixer

1 The appliance can be used for up to
5 minutes without stopping. It should
be allowed to cool each time following
prolonged, continuous operation (for
at least 20 minutes after using for
5 minutes without stopping).
Maximum processing quantities:
1
Processing in the mixing bowl must not
exceed 1.5 kg solid or 1.75 l liquid
foodstuffs.
Switching the mixer ON
(Figure 3a)
0 Select the speed range with the speed
range selector switch (Figure 1+3/C):
low speeds, or
high speeds.
0 The ON/OFF switch (Figure 1+3/B) is
used to:
– switch the mixer ON and OFF,
– control the mixer speed (5 speed set-
tings) in the pre-selected speed
range.
0 As long as the Pulse button (Figure
1+3/D) is pressed and held when the
appliance is in operation, the mixer
operates at its maximum speed.
Switching the mixer OFF
0 Slide the ON/OFF switch (Figure 1+3/B)
to "0".
– The mixer is switched off.
