USER'S MANUAL
Wireless Earphones; Model No: V0192-03; Lot No: ZZ-150/21/IMP
Product Specification:
Bluetooth version
Frequency response
SNR
Support mode
Working voltage
Working time
Stand-by time
Battery specifications
Charging case
Charging voltage
Main function
Main Material
Packing List
1. Bluetooth Earphone ----------------------------------------------------------- 2 pcs
2. Charging cable ------------------------------------------------------------------ 1 pc
3. Charging case ------------------------------------------------------------------- 1 pc
4. User's manual ------------------------------------------------------------------- 1 pc
Function Operating Instructions:
Power on (manually):long Press the TOUCH panel button for 2 seconds to turn on;
Power off (manually):long Press the TOUCH panel button for 2 seconds to turn off;
Please note: There are two ways of turn on/off the earphones : one way is automatically, another way is manually.
Automatically - First time connection - remove the earphones from charging case, earphones will boot automatically and
will be paired automatically. When you put earphones back into the charging case, they will turn off automatically
Boot back:When first time pairing is successful, the second priority earphone will be connected automatically
connected with the phone or other BT device.
Play / Pause : In the standby mode, shortly click the TOUCH panel button to play the music directly and press
the TOUCH panel button to pause the playback;
Song switch :
Long press the left earbuds touch button for 2 seconds to switch to the next song;
Long press the right earbuds touch button for 2 seconds to switch to the previous song;
During music playback, the volume can be adjusted:
Click 2 times left/right earphone - Volume increase/decrease;
Click one time the earbud to Pause/Play/Connect the call/Hang up the call;
When a phone call is coming, long press about 2 seconds to reject the call;
Click 3 times to initiate Voice assistant function
Click 4 times to Call back
Low battery prompt : When the Bluetooth headset battery power is low, it will issue a low battery tone.
Work indicator: Red lights up when charging, and when fully charged, red light goes out.
Charging:
1. Earbuds - Place the earbuds on Charging case, the earbuds indicator will turn red when charging and turn off once
charging is complete. Initial charging time is approximately 1,5 hours. Full capacity of charging case could recharge
the earbuds about 2 times.
2. Charging case - Use USB-C cable to charge the case, the case indicator will turn changing colours while charging
and turn off once charging is complete. Initial charging time is approximately 2-3 hours.
V5.1
40Hz-20KHz
106dB/±3dB
A2DP / HFP / HSP /
AVRCP / SPP
3.7V±0.5V
AROUND 3 H
50 H
40mAh*2 3.7V
300 mah with protective
plate
DC_5V Mini USB
Wireless Bluetooth, hand
free with mic
ABS
