Freestyle FS84851 Bedienungsanleitung

SPEED DIAL
S4
S3
S1. Start/stop Button
S2. Lap/reset Button
S3. Jog wheel/Mode Button
S4. Light Button
SPECIAL FEATURE
This Freestyle product features unique
Hydro Pushers®: these pushers can be
pressed under water to a dynamic water
pressure (not water depth) of 3 ATM.
DISPLAY MODES
The watch has four display modes:
HOME TIME (TIME) / FOREIGN TIME (TM-2),
HOME TIME ALARM (ALM1) / FOREIGN
TIME ALARM (ALM2), STOPWATCH (STW)
and COUNTDOWN TIMER (TMR).
To change from one display mode to
another, rotate the jog wheel or S3 button
once. The mode description will appear
for 2 seconds before the selected mode is
activated.
Note: The jog wheel can be rotated clock-
wise or counterclockwise, but the mode
sequence will only follow order listed in
above DISPLAY MODES paragraph.
HOME AND FOREIGN DISPLAY
To display FOREIGN TIME, press S2 button
when HOME TIME is displayed. The mode
description (TM-2) will appear shortly before
FOREIGN TIME is displayed. To change back
to HOME TIME, press S2 button.
To display FOREIGN TIME ALARM, press
S2 button when HOME TIME ALARM is
displayed. The mode description (ALM 2)
will appear shortly before the FOREIGN
TIME ALARM is displayed. To change back to
HOME TIME ALARM, press S2 button.
TO SET THE TIME AND CALENDAR
1. Rotate S3 button to select time mode.
2. Press S2 button to toggle between HOME
TIME and FOREIGN TIME mode to set.
3. Press and hold S2 button for 2 seconds
until the "SET" message appears and the
second digits will blink.
4. Press S1 button to reset the second digits
to 00.
5. Rotate S3 button, the minute digits will
blink.
6. Press S1 button to set the minute digits.
Holding down the button speed up the
process.
7. Rotate S3 button, the hour digits will
blink.
8. Press S1 button to set the hour digits.
9. Follow the same pattern to set date,
month, day (of the week), hour format
and calendar format.
10.To set the hour format, press S1 button
to toggle between 12-hour and 24-hour
format. The P.M. indicator may be
displayed to indicate the time period
12:00 P.M. – 11:59 P.M. in 12-hour
format.
11.To set the calendar format, press S1
button to toggle between M-D (month-
date) and D-M (date-month) format.
12.When finished making all the settings,
press S2 button to confirm.
NOTE: The chosen hour and calendar
formats will apply to both HOME TIME mode
and FOREIGN TIME mode.
All manuals and user guides at all-guides.com
NOTE: In FOREIGN TIME settings, only
minutes, hours, date, month and day are
open to setting.
TO DISPLAY THE CALENDAR
1. Rotate S3 button to select time mode.
2. Press S1 button to toggle between time
S1
display and calendar display.
Note: Calendar will be displayed for around
6 seconds before the watch switches back
S2
to time display.
TO SET THE ALARM TIME
1. Rotate S3 button to select alarm mode.
2. Press S2 button to toggle between HOME
TIME ALARM and FOREIGN TIME ALARM
mode to set.
3. Press and hold S2 button for 2 seconds
until the "SET" message appears and the
minute digits will blink.
4. Press S1 button to set the minute digits.
Holding down the button will speed up
the process.
5. Rotate S3 button, the hour digits will
blink.
6. Press S1 button to set the hour digits.
7. When finished making all the settings,
press S2 button to confirm.
TO TURN ON/OFF THE ALARM AND
HOURLY CHIME
In alarm mode,
1. Press S2 button to toggle between HOME
TIME ALARM and FOREIGN TIME ALARM
mode to set.
2. Press S1 button once to activate the
alarm. Alarm indicator
appear.
3. Press again to activate the hourly chime.
Chime indicator will appear.
4. Press the third time to activate both
functions. Both of the indicators will
appear.
5. Press the fourth time to deactivate both
functions. Both of the indicators will
disappear.
WHEN AN ALARM OR HOURLY CHIME
GOES OFF
A tune will go off by the hour if the hourly
chime function is activated.
An alarm tune will be emitted for around 20
seconds at the designated time when the
alarm is activated. To stop the tune, press
any button.
TO USE THE STOPWATCH
1. Rotate S3 button to select STOPWATCH
mode.
2. The stopwatch will then be displayed in
its current state – reset, running, or
stopped.
3. To resume a counting, press S1 button to
resume from where it left off.
4. To start a new counting, reset the stop
watch to zero first.
Press S1 button to stop counting, then
press S2 button to reset counter to zero.
For the measurement of elapsed time:
In STOPWATCH mode,
1. Press S1 button to start counting.
2. To stop counting, press S1 button once.
Press S1 button again to resume from
where it left off.
3. To reset to zero, press S1 button to stop
counting, then press S2 button to reset
the counter to zero.
For the measurement of split time:
In STOPWATCH mode,
1. Press S1 button to start counting.
2. While the stopwatch is running, press S2
button once to register a lap. The stop
watch is still running in the background.
To display the currently accumulated
time, press S2 button again.
3. Repeat the last step until all the laps have
been registered.
4. To stop counting, press S1 button once.
Press S1 button again to resume from
where it left off.
5. To reset to zero, press S1 button to stop
counting, then press S2 button to reset
the counter to zero.
NOTE: You can leave the stopwatch running
while switching over to other operating
modes.
TO SET THE TIMER
1. Rotate S3 button to select TIMER mode.
2. Press S2 button to alter the timer setting
among 1, 3, 5, 10, 15, 20, 25, 30, 45 and 60
minutes.
TO USE THE TIMER
In TIMER mode,
1. Press S1 button to start counting.
2. To stop counting, press S1 button once.
Press S1 button again to resume from
where it left off.
3. To reload the TIMER, press S1 button to
stop counting and then press S2 button.
4. After reaching zero in a countdown, a
tune will be emitted. To stop the tune,
press any button, the TIMER will reload
automatically.
NOTE: You can leave the timer running while
switching over to other operating modes.
TO USE THE BACKLIGHT
Press S4 button to turn on the backlight for
around 3 seconds.
will
To reduce carbon foot print, these
Freestyle instructions are printed with
soy inks on recycled paper.
ENGLISH
