Example 2
This example shows 4 SC6000M PRIME units with their Link ports connected to Link Ports 1–4 of a Denon DJ mixer. All
4 units are networked through the mixer.
Note: If you are using a different mixer with this setup, connect the Link ports of all 4 SC6000M PRIME units to an
Ethernet hub instead of to the mixer.
SC6000M PRIME
(rear panel)
Power
outlet
SC6000M
PRIME
(rear panel)
Power
outlet
RF Warning: This is a mobile device. Maintain a distance of at least 8 inches / 20 centimeters of separation between the transmitter's
radiating structure(s) and your body or other people nearby.
6
USB
drive
Denon DJ mixer
(rear panel)
SD card USB drive
SC6000M PRIME
(rear panel)
USB
drive
SC6000M PRIME
(front panel)
Power
outlet
SC6000M
PRIME
(rear panel)
Power
outlet
