Tangent Danmark spectrum X5 BT Bedienungsanleitung Seite 10

CONNECT A TURNTABLE
PHONO
[For use with a turntable without built-in phono pre-amp]:
Slide the Phono/ Line switch to phono position.
Connect the RCA L/R from your turntable to the RCA L/R inputs on the rear panel of
the Tangent Spectrum X5 or X6 BT.
Connect the ground wire from the turntable to the GND on the rear panel of the
Tangent Spectrum X5 or X6 BT.
Press AUX 1 on the Tangent Spectrum
SPECIFICATIONS
Speaker Type:
Tweeter/Midrange/Woofer:
Amplifier power:
Sensitivity:
Frequency response:
Amplifier type/AC Power:
Input Connections:
Cabinet finish:
Cabinet[WxDxH]mm:
Net weight [Kg]
AUDIO
X5 or X6 BT remote.
X5BT
Powered Speaker
1"/ 1x5"
2x50W
88dB
60Hz-20kHz
Class-D / AC100-240V/50-60Hz
Bluetooth/jack 3.5/Line RCA/Optical/Coaxial/Phono
Black matt or White matt painting
166 x 205 x 340mm
4 kg/ unit
X6BT
Powered Speaker
1" / 2x5"
2x60W
90dB
50Hz-20kHz
66 x 268 x 923mm
13,5 kg/ unit
