INSTRUCTIONS FOR FUNCTIONS AND CONTROLS
LOW LEVEL OUTPUT
1
A daisy chain output for connection to another amplifier with a low level input using only a
single RCA output from the source(head unit)
LOW LEVEL INPUT
For connection to any source (head unit) with a low level output. This is your RCA output
from the source (head unit).
2
GAIN Knob for volume adjustment.
LPF
3
Low pass frequency adjusting knob, the frequency ranges from 40Hz to 180Hz.
SUBSONIC
4
Subsonic frequency adjusting knob, the frequency ranges from 17Hz to 50Hz.
BASS FREQ
5
The boost ranges from 30Hz to 80Hz.
BASS BOOST
6
The boost ranges from 0dB to 12dB.
INDICATOR LIGHT
7
When this LED sends out green light, it means that this amplifier have being working now.
When this LED sends out red light, it means that the self-protection of the amplifier.
