Ma in Scre e n
The m ain screen o f t he remot e co nt ro l so ftw are:
A Current adj ustm ent
B Current display ( am pere)
C Vo lt age adj ustm ent
D Vo lt age display ( vo lt )
E Overcurrent pro t ect io n
F Vo lt age graph: show s t he vo lt age o ver t im e
Se tt ing Vo lt a ge a nd Curre nt
To set t he vo lt age and current [ A,C] yo u can:
•
select a value from t he list
•
drag t he sliders. Tip: yo u can click o n t he slider and use t he scro ll w heel o f yo ur mo use.
The set value appears in t he bo x to t he right o f t he slider .
Apply ing Vo lt a ge t o t he Loa d
Press t he ON key [ J] to apply vo lt age to t he load.
Press t he OFF key [ I ] to sw it ch t he o ut put o ff.
Using Ov e rcurre nt Prot e ct ion
To pro t ect against o vercurrent , set up t he m axim um current and t hen select Out put sw it ch off in t he
Curre nt prot e ct io n se t up bo x [ E] .
To sw it ch o vercurrent pro tect io n o ff, select Ove rcurre nt prot e ct ion of f.
V. 0 3 – 25 / 08 / 20 14
All manuals and user guides at all-guides.com
LABPS3 0 0 5 D
G Current graph: shows t he current o ver t im e
H Lo g
I Out put o ff
J Out put o n
K Comm unicat io n st at us
