COMPLETE TOOL
Item Description
1 Adapter 3/8" BSP
2 Silencer
3 Spacer
4 O-Ring
5 Spring
6 Valve
7 Spring-throttle
8 Throttle
9 Tube inlet
10 Seat throttle
11 Pin valve
12 O-Ring
13 Safety lever
14 Roll pin
15 Motor housing
17 Governor 24K
18 Ball bearing
19 Gasket
20 Roll pin
21 Rear plate
22 Vane
23 Rotor
24 Cylinder
25 Front plate
26 Spacer
27 Ball bearing
28 Spacer
37 Chuck
39 Nut collet
40 Flange
41 Adjusting nut
42 Circlip
43 Bearing
44 Router nose
45 Machined routing guide
46 Router nose assembly kit
47 Warning instructions
08/2013 5 / 36
6159947340_03
Series: B
Part No Qty
746.64
574.197
643.75
658.164
681.98
155.12
681.97
155.11
430.23
321.170
312.80
658.198
321.154
637.145
6153962340
457.19
758.94
656.148
637.113
422.144
434.53
426.84
400.131
420.131
660.53
753.64
645.132
523.23
607.144
6155952450
6156071450
6156870560
6157581270
6155421320
6155421310
6153962890
6158726110
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
3
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
