Model
UVC tubes (power/type)
Service life of the UVC tube
Degree of protection / protection class
Length of connecting cable for pump with UVC clarifier
Maximum temperature of the pumped liquid (T
Minimum temperature of the pumped liquid
For ponds up to
Pump outlet
Weight (net)
Item number
1)
The specified maximum capacities have been determined with a free, unreduced outlet.
4. Application areas and mode of operation
The TFU 2000 UV 9 is a compact, installation and maintenance-friendly replaceable filter designed for
cleaning of small ponds, raised ponds and aquariums. This ensures that the water in the pond stays clear
and clean.
The device has been developed for private use and not for industrial or commercial purposes.
This replaceable filter system is used to support the biological self-cleaning of your raised pond. A
satisfactory effect and function of this replaceable filter system is influenced by various operating conditions.
Factors, such as many fish, few plants, a lot of direct sunlight and a high level of contamination can
negatively influence the mode of operation and may significantly reduce the maximum pond water volume
that can be effectively cleaned.

5. Placing in service

Do not use excessive force that can cause damage when tightening threaded unions.
5.1. Assembly
Make sure that the pump is positioned correctly and that the filter cap is removed from the bottom.
Connect the plugs to power the pump with UV clarifier and put the filter into operation.
5.2. Setting up at the garden pond
For biological reasons, the immersion depth of the pond pump should be approx. 40 cm for optimal function
of the filter system. Ensure that the pond pump is placed on a silt-free base (stone slab).
5.3. Commissioning
Attention! Comply with the safety measures specified for the UVC clarifier and the pump (see above)!
Install the connection sockets in the water-protected area and at least 2 m away from the edge of the
pond!
Connect the pond pump with UVC clarifier to the mains supply, plug the mains plug into the socket outlet.
The pond pump pumps the contaminated water through the integrated UVC clarifier and cleans it.
You can check the function of the UVC tube by the bluish shimmer on the transparent intermediate ring of
the UVC clarifier (can be seen more easily with the filter cap removed). This check works best in low light.
For this filter system we recommend continuous operation (24 hours a day), in the season months March to
October.
Attention! The function of the filter system must be checked at regular intervals!
Initially, the filter system should be checked at least once a day. Leaves, grass, and animal hair, for example
can quickly clog the filter sponges.
Consequently select the cleaning intervals based on the type and the extent of contamination in your pond.
10
)
max
3
TFU 2000 UV 9
9 W / G23
ca. 4000 hours
IPX8 / I
10 m (05NR8-F)
35°C
5 °C
4,000 l
13 mm
2.9 kg
30429
