Cameo CLLDFORCEAPSSL Bedienungsanleitung

CLLDFORCEAPSSL
Adapter for use of Pangolin Safety Scan lenses with
CAMEO D. FORCE show lasers
SAFETY INFORMATION
1. Please read these instructions carefully.
2. Keep all information and instructions in a safe place.
3. Follow the instructions.
4. Observe all safety warnings. Never remove safety warnings or other information from the equipment.
5. Use the equipment only in the intended manner and for the intended purpose.
6. Use only sufficiently stable and compatible stands and/or mounts (for fixed installations). Make certain that
wall mounts are properly installed and secured. Make certain that the equipment is installed securely and
cannot fall down.
7. During installation, observ e the applicable safety regulations for your country.
8. Never install and operate the equipment near radiators, heat registers, ovens or other sources of heat. Make
certain that the equipment is always installed so that is cooled sufficiently and cannot overheat.
9. Never place sources of ignition, e.g., burning candles, on the equipment.
10. Ventilation slits must not be blocked.
11. This appliance is designed exclusively for indoor use, do not use this equipment in the immediate vicinity
of water (does not apply to special outdoor equipment - in this case, observe the special instructions noted
below). Do not expose this equipment to flammable materials, fluids or gases.
12. Make certain that dripping or splashed water cannot enter the equipment. Do not place containers filled
with liquids, such as vases or drinking vessels, on the equipment.
13. Make certain that objects cannot fall into the device.
14. Use this equipment only with the accessories recommended and intended by the manufacturer.
15. Do not open or modify this equipment.
16. After connecting the equipment, check all cables in order to prevent damage or accidents, e.g., due to
tripping hazards.
17. During transport, make certain that the equipment cannot fall down and possibly cause property damage
and personal injuries.
18. If your equipment is no longer functioning properly, if fluids or objects have gotten inside the equipment or
if it has been damaged in anot her way, switch it off immediately and unplug it from the mains outlet (if it is a
powered device). This equipment may only be repaired by authorized, qualified personnel.
19. Clean the equipment using a dry cloth.
20. Comply with all applicable disposal laws in your country. During disposal of packaging, please separate
plastic and paper/cardboard.
21. Plastic bags must be kept out of reach of children.
FOR EQUIPMENT THAT CONNECTS TO THE POWER MAINS:
22. CAUTION: If the power cord of the device is equipped with an earthing contact, then it must be connected to
an outlet with a protective ground. Never deactivate the protective ground of a power cord.
23. If the equipment has been exposed to strong fluctuations in temperature (for example, after transport), do
not switch it on immediately. Moisture and condensation could damage the equipment. Do not switch on the
equipment until it has reached room temperature.
24. Before connecting the equipment to the power outlet, first verify that the mains voltage and frequency
match the values specified on the equipment. If the equipment has a voltage selection switch, connect the
equipment to the power outlet only if the equipment values and the mains power values match. If the included
power cord or power adapter does not fit in your wall outlet, contact your electrician.
25. Do not step on the power cord. Make certain that the power cable does not become kinked, especially at
the mains outlet and/or power adapter and the equipment connector.
26. When connecting the equipment, make certain that the power cord or power adapter is always freely
accessible. Always disconnect the equipment from the power supply if the equipment is not in use or if you
want to clean the equipment. Always unplug the power cord and power adapter from the power outlet at the
plug or adapter and not by pulling on the cord. Never touch the power cord and power adapter with wet hands.
27. Whenever possible, avoid switching the equipment on and off in quick succession because otherwise this
can shorten the useful life of the equipment.
28. IMPORTANT INFORMATION: Replace fuses only with fuses of the same type and rating. If a fuse blows
repeatedly, please contact an authorised service centre.
29. To disconnect the equipment from the power mains completely, unplug the power cord or power adapter
from the power outlet.
30. If your device is equipped with a Volex power connector, the mating Volex equipment connector must be
unlocked before it can be removed. However, this also means that the equipment can slide and fall down if
the power cable is pulled, which can lead to personal injuries and/or other damage. For this reason, always be
careful when laying cables.
31. Unplug the power cord and power adapter from the power outlet if there is a risk of a lightning strike or
before extended periods of disuse.
32. The device must only be installed in a voltage-free condition (disconnect the mains plug from the mains).
33. Dust and other debris inside the unit may cause damage. The unit should be regularly serviced or cleaned
(no guarantee) depending on ambient conditions (dust etc., nicotine, fog) by qualified personnel to prevent
overheating and malfunction.
34. Please keep a distance of at least 0.5 m to any combustible materials.
The warning triangle with lightning symbol indicates dangerous uninsulated voltage inside the
unit, which may cause an electrical shock.
The warning triangle with exclamation mark indicates important operating and maintenance
instructions.
CAUTION: CHARGING OF THE PAR LIGHTS IS ONLY ALLOWED BY OPEN CASE / LID.
MANUFACTURER'S WARRANTY & LIMITATION OF LIABILITY
You can find our current warranty conditions and limitation of liability at: https://cdn-shop.adamhall.com/media/
pdf/Manufacturers-Declarations-CAMEO_DE_EN_ES_FR.pdf
To request warranty service for a product, please contact Adam Hall GmbH, Adam-Hall-Str. 1,
61267 Neu Anspach / Email Info@adamhall.com / 49 (0) 6081 / 9419-0
PROPER DISPOSAL OF THIS PRODUCT (WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT)
(Valid in the European Union and other European countries with waste separation)
This symbol on the product, or the documents accompanying the product, indicates that this appliance may not
be treated as household waste. This is to avoid environmental damage or personal injury due to uncontrolled
waste disposal. Please dispose of this product separately from other waste and have it recycled to promote
sustainable economic activity.
Household users should contact either the retailer where they purchased this product, or their local government
office, for details on where and how they can recycle this item in an environmentally friendly manner.
Business users should contact their supplier and check the terms and conditions of the purchase contract. This
product should not be mixed with other commercial wastes for disposal
CAUTION:
To reduce the risk of electric shock, do not remove cover (or
back). There are no user serviceable parts inside. Maintenance
and repairs should be exclusively carried out by qualified service
personnel.
Adam Hall GmbH · Adam-Hall-Str. 1 · 61267 Neu-Anspach · Germany
Tel.: (+49) 60 81 / 94 19 0 · Fax: (+49) 60 81 / 94 19 1000 · eMail: mail@adamhall.com
MOUNTING
1 Switch off the show laser, unplug it from the mains and remove the cover panel
for limiting the laser beam output areas from the frame of the laser emission window
(remove knurled screws).
2 Remove the three countersunk screws (A) of the adapter cover using a 2 mm
hexagonal tool and take the cover off the adapter frame. Take care to ensure that the
four attachment screws (B) do not protrude inwards. Place the Safety Scan lens in the
adapter frame, position the cover back on the frame and attach it using the screws
previously removed. Now attach the Safety Scan lens using the four screws (B), tak-
ing care to ensure that the lens is not damaged. Use a 2 mm hexagonal tool for this
purpose.
3 Now place the adapter on the frame of the laser emission window and attach it
using the knurled screws provided (C). While doing so, ensure that the white plastic
washers are correctly positioned on the screws (D). The adapter can be adjusted in
height in the same way as the cover panel.
Check the adapter regularly to make sure it is firmly attached in the correct
position and take care to ensure that the position cannot change even if the
device is exposed to heavy vibrations!
TECHNICAL SPECIFICATIONS
Article number: CLLDFORCEAPSSL
Product type: Accessories for Cameo D. FORCE show laser
Type: Adapter for Pangolin Safety Scan lenses
Colour: Black
Material: Metal
Dimensions (W x H x D): 84 x 71 x 12 mm
Weight: 0.085 kg
B
C
C
A
D
