intake screen, and then the impeller cover.
3. Lift out the impeller
4. Thoroughly clean the impeller to remove slime, dirt or debris.
5. Place the impeller back into the impeller cavity. Replace the
impeller cover, then replace the intake screen.
Note: If you are using well water, or if you have hard water, run the
pump for a few minutes in a 50/50 solution of water and vinegar to
help remove calcium deposit buildup before replacing the pump.
Caution:
Do not use detergents or other chemical cleaners. The power cord
cannot be replaced, discard the appliance if damaged.
PUMP
Troubleshooting:
6
Caution:
The pump must not be allowed to run dry. If pump fails to operate,
check the following:
No Flow:
• Check if the power supply is on. Check the circuit breaker or try
another outlet to ensure the pump is getting electrical power.
Note: always disconnect pump from electrical supply before
handling the pump.
• If power supply is working but pump is not, then it may be
clogged by debris. Disconnect the pump, check intake screen to
ensure it is not clogged, then follow the maintenance procedures
to clean impeller.
Low Flow:
• Check hose for sharp bends or blockage
• Check the pump's output tube to ensure it is not clogged by
debris
• Check the pump's intake screen to ensure it is not clogged
by debris. Then follow the maintenance procedures to clean
impeller
Pump Specifications:
Voltage
Frequency
Wattage
Flow Rate
Water Column
Vol. at 12in/30cm
IMPELLER COVER
IMPELLER
cUL
110V – 115 V
60 Hz
2.19 W
45 US Gph
19.6 in (50 cm)
30 gph
INTAKE SCREEN
CE
230 V
50 Hz
2.6 W
150 lph
40 cm
98 lph
