Indoor Unit ACQ 71/100/125/140 DV1
Dimension
A
Model
ACQ 71 DV1
820
ACQ 100 DV1/
ACQ 125 DV1/
820
ACQ 140 DV1
Note is valid for Turkey only: The lifetime of our products is ten (10) years

OUTLINE AND DIMENSIONS

B
C
D
B C D
820 340 300
820 375 335
1-1
F
E
H
K
E F G H
40 990 990 627
40 990 990 627
All dimensions are in mm
I J K
627 607 430
627 607 430
