Vaporesso COSS Bedienungsanleitung Seite 3

1. Fill capsule and 2. When there is no
put it back into HUB liquid or less liquid
(save this step if in the stick, put it
capsule is full) back
5. FILLING SAFETY SYSTEMS
① When filling, please hold the hub vertically upwards, it cannot be filled when tilted
or lying flat. If it is tilted or lying flat during filling, the hub stops filling and the filling
indicator flashs 5 times quickly;
② Do not shake the hub too fast when filling. When the hub senses the rapid shaking,
the hub will stop filling, and the filling indicator will flash 5 times quickly;
③ If you continuously refilled for the second time, the filling indicator flashes 5 times ,the
fill protection function is triggered to prevent the liquid from overflowing;
④ To deactivate the fill protection, please toggled the front button, then you can fill again
⑤ 5.For better vaping experience, please do not fill the liquid exceed the MAX line
Note: when you start a new pod, maybe you need to fill 2 or more times to reach the MAX
line
⑥ During filling, please remain the stick in the hub and not to vape
✔
Vertical direction
✘
Tilted
3. Hold it in vertical 4. Automatic filling
direction, press the is completed
filling button to
refill
Shake rapidly
Lay flatly
6. BATTERY LEVEL
After push the front button, the 4 battery indicators will display as follows
100%-75%
●
●
●
●
*The stick cannot be refilled or recharged while the battery of the hub is low, the hub's
last battery indicator will flash 5 times quickly for reminding;
7. CHARGE THE STICK'S BATTERY
The stick will be automatically recharged when it is inserted into the hub. And the hub's
battery indicator keeps breathing while charging; After the stick is fully charged, the
5. Check the liquid
amount, do not
breathing indicator will be off.
exceed MAX line
8. CHARGE THE HUB'S BATTERY
The hub is charges with a USB-C cable. Under charging status, the battery level indicator
lights up gradually. After the hub is fully charged, all the battery indicators will be on. In
case of overcharge, please remove the USB-C cable after fully charged.
9. SHORT-CIRCUIT PROTECTION
The VAPORESSO COSS is equipped with a safety system. If the device detects a short
circuit, the last battery indicator flashes 10 times , the charging process stops and the
current battery level will be displayed.
EXPLODED VIEW
✘
Battery Indicator
VAPORESSO COSS STICK SPECIFICATION
✘
Size: 17 x 9 x 93.5 mm
Pod Capacity: 0.6ml
Resistance: 1.2Ω
Stick- Battery Capacity: 250mAh
Output Voltage: 3.3V-4.3V
Output Wattage: 9W
75%-50% 50%-25% 25%-0%
○ ○ ○
● ○ ○
● ● ○
● ● ●
POD
Stick
E-Juice Injection Point
Magnetic contact pin
