User Manual
Package Contents
• Wireless Speaker Boogie
• Micro-USB charging cable
• Stand
• User Manual
If any of the above pieces is missing, please pack the product again and bring it back to
your dealer.
Overview:
1. Status LED (blue)
6. Charging LED (red)
2. Lautsprecher
7. Vol+ / next track
3. TF Card slot
8. Micro-USB Charging port
4. Vol- / previous track
9. USB Port
5. Multifunction Button
10. Stand holder
- Musik Start-Stop ( ) 11. Stand
- Mode ( )
- On /Off Switch ( )
2
1
Front view
Getting started
Mount stand
Insert the supplied stand (11) with the straight side all the way into the stand holder (10) on the
back of the boogie.
Charging the battery
Boogie is equipped with an internal rechargeable lithium-Ion battery. Connect the Micro USB cable
with the micro USB charging port (8) of the Boogie. The cable can be connected to a computer or
a standard USB power adapter. The red LED (6) of Boogie lights up while charging.
The normal charging time is 2-3 hours. The red LED (6) turns off when fully charged. The cable
can be disconnected.
Note: Charge Boogie for at least 2.5 hours before initial use.
Switching On /Off
Switch on: When powered off, press and hold the right side ( ) of the multifunction button (5).
Switch off: Press and hold the right side ( ) of the multifunction button (5).
Pairing
Boogie must be paired with a Bluetooth ® device before use.
This is a two part process; fi rst part is carried out on the Speaker and the second is carried out on
the other Bluetooth ® device.
Note: Please note that different mobile phones may require different pairing methods.
1. Make sure that Boogie is powered off, press the right side ( ) of the multifunction button (5).
The Speaker turns on and the pairing mode will start.
2. Use your mobile phone, computer or another Bluetooth
Bluetooth audio devices.
®
3. The Bluetooth device should indicate that it has found „Boogie".
®
4. Confi rm pairing with Boogie. Enter „0000" if you are asked for a pairing code.
If you are unsure about the pairing procedure of your Bluetooth
device manual.
If using a Bluetooth® transmitter without display, set it to pairing mode and wait a few seconds
until the connection with Boogie is established.
Note: If the connection is lost or the transmitter is temporarily disconnected, Boogie automatically
tries to restore the connection. If the connection cannot be restored after 3 seconds, try again by
pressing the multifunction button (5) for two seconds.
i
Connect a second Boogie speaker
In Bluetooth ® mode, it is possible to connect a second Boogie speaker wirelessly to
achieve excellent stereo sound.
To connect two boogie speakers together, turn on both devices at the same time. The de-
vices start in pairing mode and connect after 2-3 seconds. Now switch on your previously
with one of both Boogie Speaker paired mobile phone (Description of pairing see above),
and activate the Bluetooth function. The device will automatically connect. The adjust-
®
ment of the volume and the music control is done only via one of the two speakers.
BT Speaker „Boogie"
4 5 6 7
Rear view
3
8
9
10
11
® transmitter in order to search for
device, please check your
®
Technische Änderungen vorbehalten / Fontastic, by D-Parts Mobilphon & Zubehör GmbH ● Birkenweiherstr, 16 ● 63505 Langenselbold, Germany / V1_11_17
Musik playback
Music playback via Bluetooth ®
Start music playback on the Bluetooth source which is paired with the Boogie. The music is
®
transferred to the Boogie. Stop the music playback on the Bluetooth
streaming.
Note: The device must support the A2DP profi le for music streaming and AVRCP profi le for
music remote control. Redial is deactivated during music playback.
.
Play music from memory card
Insert a memory card with audio data into the TF socket (3) of the boogie. The data stored on the
memory card will be played immediately.
Play music from USB memory
Insert a USB stick with audio data or a USB cable, connected with a Audio source to the USB
socket (9) of the boogie. The stored audio data will be played immediately.
Music control
To play or stop music playback, briefl y press the left side ( ) of the multifunction button (5).
To skip to the previous track, press the previous track button (4).
To skip to the next track, press the next track button (7).
Hands-free features
With its built-in microphone and intelligent noise reduction, the Boogie is perfectly suitable for
phone calls.
Answer/end/reject calls
To accept an incoming call, briefl y press the multifunction button (5).
To end a call in progress, briefl y press the multifunction button (5).
To reject incoming calls, press and hold the multifunction button (5) for 2-3 seconds.
Adjusting the Volume
To increase the volume, press and hold the volume + button (7) until the desired volume is
reached.
To decrease the volume, press and hold the volume - button (4) until the desired volume is
reached.
Technical Specifi cations:
• BT V 4.2
• Operating range: Up to 10 m
• Profi le: Hands free, Headset, A2DP/ AVRCP
• BT Frequency: 2.402-2.480GHZ, 2.4G
• TF Cardslot
• Speaker: Ø 40mm / 4Ω /3Watt
• Built-in Microphone
• LED: Blue/Red
• Micro USB Charging port
• Power Input: 5V DC
• Rechargeable 300mAh Lithium-Ion Battery
• Operation time: 2-3 hrs.
• Dimensions: Ø 124 mm / Depth 45 mm
• Weight: 178 g
Safety advice:
• Do not open the device
• Do not hold the device under water
• Keep it safe from humidity
• Do not connect the adapter to the device by using force
• Keep the device away from children
• Disconnect electronic devices from the power when not using them for longer time.
• Do not use the device when it has visible defects.
In case you need technical support, please contact our support-team by e-mail under
service@fontastic.eu.
Registration and Safety
Certifi cation/General Information
We hereby declare, that this device carries the CE mark in accordance with the regulations
and standards. It conforms with the fundamental requirements of the (RED) 2014/53/EC,
EMC directive 2004/108/EC as well as the Low Voltage Directive 2014/35/EC.
Note on environmental protection:
After the implementation of the European Directive 2012/19/EC in the national legal
system, the following applies:
Electrical and electronic devices may not be disposed of with domestic waste.
Consumers are obliged by law to return electrical and electronic devices at the end of
their service lives to the public collecting points set up for this purpose or point of sale. Details
of this are defi ned by the national law of the respective coun-try. This symbol on the product, the
instruction manual or the package indicates that a product is subject to these regulations. By re-
cycling, re-using the materials or other forms of utilising old devices, you are making an important
contribution to protecting our environment.
