GB
Please read carefully these Operating Instructions before putting the appliance into operation
A.V. 2 Any reprints, even in abbreviated version, are subject to approval. Technical changes reserved.
Do you have any questions? Any claim? Do you need spare parts or operating instructions?
We will quickly help you and without bureaucracy at our homepage
In order to identify your device in case of claim we need the serial No., assortment item No. and year of production. All this data can be found on
GB
the type label. Please enter it here for future reference.
Serial No._____________________________Product No.___________________________Year of production:_______________________
Tel.: +49 (0) 79 04 / 700-360
Symbols: product safety, commands:
Product complying with respective EU standards
Ratchet screwdriver 1/2" PRO
Hardy, chromium plated, polished finish. Extremely high torque (110 Nm),
owing to which additional tightening is not necessary. Softgripp heated
handgrip. Tool bracket of high quality. Low vibrations, long-life gearing
right/left from the gear on the head. Air outlet on pneumatic coupling to provide
for nice work. Continuous adjustment of speed.
It includes a connecting plug of a usual nominal width 7,2.
Unit Scope of Supply (Fig. 1)
1. Handle
2. Pneumatic coupling
3. Control lever
Tool hold
4.

EC Declaration of Conformity

GB
We, Güde GmbH & Co. KG Birkichstraße 6, 74549 Wolpertshausen, Germany,
hereby confirm the following appliances correspond – on a basis of their
conception and their construction type and in designs launched by us – to
appropriate basic requirements of directives of the European Community
concerning occupational health and safety.
In case of any change to appliances not approved by us the Declaration
expires.
Marking of appliances: Ratchet screwdriver 1/2" PRO
Order No.: 75140
Date/producer signature: 03.01.2012
Signed by: Mr Arnold, Managing Director
Respective EU standards:
2006/42/EC
Harmonised standards used:
EN 792-6+A1:2008
Guarantee
Guarantee claims according to the guarantee certificate attached. Please,
understand that we are unable to accept the guarantee for the following
reasons:
• Breach of operation and service instructions .
Necessary cleaning neglect.
• Forcible use, unprofessional handing, misuse or accident.
• Laic interventions or unprofessional attempts to do a repair.
General Safety Directions
Read the operation manual carefully .
Get familiar with the adjustment and correct use of the unit
Assigned Use
The adjustment screwdriver is a pneumatic tool to do craft works
easily. It works very well on motor vehicles, motorcycles,
agricultural machines or assembly belts, primarily on hardly
accessible places. To obtain a maximum torque, additional
fastening by hand with ratchet screwdriver is not permitted.
Waste air comes out in the forward part of the body. Pneumatic
www.guede.com
Fax: +49 (0) 79 04 / 700-51999
Use protection goggles and ear protectors
5
in the Servicing part. Please help us be able to help you.
E-Mail: support@ts.guede.com
Read the operation manual before use
coupling is formed by fast-acting clutch.

Safety Provisions

Protect yourself and those around against accidents with suitable safety
means.
•
Do not touch the rotating parts.
• The ratchet screwdriver should not be used in contrary to
determination.
•
Protect the pneumatic tools from children.
• Get down to work well-rested and concentrated.
•
Pneumatic connection via a fast-acting clutch only.
•
Set-up the work pressure on reduction valve.
• Do not use oxygen or inflammable gases as the source of energy.
•
Before removing failures, disconnect the unit from the source of
pressure air.
• Use only the genuine spare parts.
•
Never let the unit idle at full.
•
When working with a ratchet screwdriver, always wear required
protection suits and ear protectors.
Technical Data
Operating pressure:
Air consumption:
Air connection crew thread:
Max. torque:
Speed
Recommended hose Cross-section :
Weight:

Initial Operation

Screw the plug-in clutch included in the delivery (pos. 2) screw in the
reduction clutch. Use a box-end or a forked wrench for it.
Notice: Tighten the thread with a Teflon tape.
Pull a required socket wrench insert on the drive (pos.4). Connect the air
hose and a fast-acting clutch to the plug-in clutch. Put the socket wrench
insert on the screw or the nut being released/tightened. Set-up the required
direction of turning on the switching lever (Fig.2) and pull the draw-off lever
(pos. 3).
The required speed and torque may be set up with a screw on the hand grip
(Fig. 3).
Maintenance and Care
Observing warning commands shown in the manual will provide this high
quality product long service life and fault-free operation. Lasting and trouble-
free function of your ratchet screwdriver is grounded on regular lubrication.
Use only a special tool oil. Pick up a possibility of lubrication. :
b) Via a beam added lubricator
The full maintenance unit include a beam added lubricator and is placed on
the compressor.
c) Via a lubricator on the piping
A lubricator installed on piping supplying the unit with sufficient amount of oil
in an immediate distance from the unit (approximately 50 cm).
c) manually
If there is no maintenance unit or a lubricator on piping , 5-6 drops of oil
should be put in pneumatic connection before every putting in operation.
Store the pneumatic tool in dry rooms only.
6,3 bar
180-540 l/min
1/4"
110 Nm
-1
160 min
10 mm
1,4 kg
