Putting Into Operation - FAME Analog Delay Bedienungsanleitung

Installation:
Be sure to inspect the product for damage before using it. Optimally, use the original packaging or
suitable transport or storage packaging to protect the product from dust, moisture, etc. when not in
use.

Putting into operation:

All connections of the device should be made before switching on. Only use high-quality cables that
are as short as possible for the connections.
1 BYPASS foot switch
2 LED
3 TIME controller
4 FEEDBACK controller
5 ECHO controller
6 Input
7
Output
8 DC IN connection
Used to switch the effect unit on/off.
Displays pedal status
Determines the time value of the effect.
Determines the intensity of the effect
Determines the tonal coloration of the effect
Input jack for standard instrument cable (6.3mm mono jack)
With a standard instrument cable, you can connect to these
output another effects pedal or your amplifier
connect
For connecting a power supply DC 9V (-) inside
