7 Scope of delivery

Microscope (A); 10x WF Eyepiece (B); 4 Objectives (pre-assembled) (C); Condenser (pre-assembled)
(D); Power adapter with plug and cable (E)

8 Parts overview

1 Trinocular head* / photo adapter*
2 Eyepiece
3 Eyepiece holder
4 Microscope head
5 Objective nosepiece
6 Objective
7 Specimen clamp
8 Condenser height adjustment
9 Condenser
10 Illumination
11 Adjusting lever for iris diaphragm
12 Rotary knob for brightness adjustment
13 Fine focusing
14 Coarse focusing
15 Cross table lateral adjustment (X-axis)
16 Cross table longitudial adjustment (Y-axis)
17 On/Off switch
18 DC power port
19 Universal USB power adapter
20 USB power cable with coaxial/barrel connector
21 Power adapter attachment (EU)
22 Power adapter attachment (UK)
8 / 32
