Thank you for purchasing one of our units and welcome into the Gold Note world, where we turn High-End audio and music into a new experience. Maurizio Aterini, founder of Gold Note...
Seite 4
When a cart is used, use caution when moving the cart/apparatus combination to Gold Note does not have responsibility avoid injury from tip-over. for any improper use of this unit. Unplug this apparatus during lightning...
Seite 5
Refer only to qualified Gold Note service personnel for service. GOLD NOTE - Information on the correct management of waste from household Equipment pursuant to the European Directive 2012/19/EU The crossed-out wheelie bin symbol shown on the equipment or its packaging indicates that the product, at the end of its useful life, must be collected separately from other waste to allow its proper treatment and recycling.
| INDEX TECHNICAL SPECIFICATIONS UNBOXING AND ASSEMBLY CONNECTING THE LOUDSPEAKERS POSITIONING THE LOUDSPEAKERS LOUDSPEAKERS SETUP PRODUCT REGISTRATION TROUBLESHOOTING | PACKAGE CONTENT SPIKE FEET SPIKE PADS XS-85 ALLEN KEY M4x40mm USER SCREWS MANUAL with washers...
1“ silk dome driver Midrange: 2 x 6“ Nextel treated paper cones Woofer: 2 x 9“ Nextel treated paper cones Suggested power amplifier: min. 30W Max power handling: 300W RMS Crossover: 200Hz and 2200Hz @ 12dB/Oct. Connectors: Gold Note Rhodium binding posts...
Seite 9
| UNBOXING AND ASSEMBLY Spike feet (x4) M4x40 (x6) Repeat each step for both speakers. STEP 3 STEP 1 Take the foot as shown in the picture above Open the Foot box and gently remove the and use the guides to correctly position the foot from the box, then place the Mid-range foot on the woofer cabinet.
Seite 10
STEP 4 STEP 6 Once the foot is assembled, pay extreme Remove all the screws from the back of the care in turning the cabinet and make sure midrange cabinet, then remove the vented to protect it with soft material to avoid aluminium back grille as shown in the damaging the surfaces.
Seite 11
Mid-High speak-on cable M4x40 (x4) STEP 7 Secure the midrange cabinet and the woofer cabinet to each other with the four M4x40 Allen screws supplied, as shown in the picture. STEP 8 Connect the midrange speak-on cable to the connector of the woofer cabinet: insert it and turn clockwise in order to lock it in place correctly.
POSITIONING THE | LOUDSPEAKERS CEILING The dimensions of your listening room don’t have as much of an effect on the audio quality as the position of the loudspeakers so High ceilings tend to offer better results, with we recommend placing them carefully. The an ideal constant height of 2,50m to 3,60m.
Seite 15
(such as bookshelves, bookcases and record them between the speakers or to the side racks). of the system. The Gold Note Galileo rack features a special curved design to effectively diffracting the sound waves OPPOSITE WALL and can therefore be placed between the loudspeakers.
Seite 16
In the same way, the distance between each loudspeaker and the closer sidewall should be approximately the same as the distance between them and the back wall. XS-85 XS-85 Loudspeakers distance Listening point...
Any service and inspection must be carried out by a Gold Note dealer or distributor so If the unit is not registered correctly or has in case you need any assistance with this been purchased from a different country of product, please contact the seller.
Seite 18
| TROUBLESHOOTING PROBLEM CAUSE SOLUTION The loudspeakers make a The loudspeakers are not Check that the system humming noise. correctly grounded. and the rest of the room is grounded correctly. The interconnect input Always use shielded and/or output cables are cables.
Seite 19
Vielen Dank, dass Sie sich für eines unserer Geräte entschieden haben und herzlich Willkommen in der Welt von Gold Note, wo wir High-End Audio und Musik in eine neue Erfahrung verwandeln. Maurizio Aterini, Gründer von Gold Note...
Steckern, Steckdosen und mitgelieferte Netzkabel darf nur an an der Stelle, an der sie aus dem Gerät diesem Gerät verwendet werden. austreten. Gold Note übernimmt keine Verwenden Sie nur die vom Hersteller Verantwortung für Schäden durch angegebenen Anbaugeräte/Zubehörteile. unsachgemäße Handhabung.
Seite 21
Für die Wartung wenden Sie sich ausschließlich an qualifiziertes Gold Note Servicepersonal. GOLD NOTE - Information zum korrekten Umgang mit Elektro- und Elektrogeräte-Abfall gemäß der WEEE-Richtlinie 2012/19/EU des Europäischen Parlaments Das Symbol der durchkreuzten Abfalltonne auf Rädern auf Geräten oder...
| AUSPACKEN UND MONTAGE Spikes M4x40 (x6) SCHRITT 3 Alle Schritte für beide Lautsprecher wiederholen. Den Standfuß wie in der Abbildung gezeigt und mithilfe der Richtlinien auf dem SCHRITT 1 Tieftongehäuse positionieren. Den Karton des Standfußes öffnen und Die mitgelieferten Spikes wie in der vorsichtig auspacken.
Seite 26
SCHRITT 4 SCHRITT 6 Sobald der Standfuß montiert ist, das Alle Schrauben auf der Rückseite des Gehäuse mit großer Vorsicht aufstellen und Mitteltongehäuses entfernen und dann das dabei mit einem weichen Material schützen, rückseitige Aluminiumgitter abnehmen, wie um die Oberfläche nicht zu beschädigen. in der Abbildung gezeigt.
Seite 27
Mittelton- Lautsprecherkabel M4x40 (x4) SCHRITT 7 Wie in der Abbildung die Gehäuse von Mittel- und Tieftönern anhand der vier mitgelieferten M4x40 Schrauben verschrauben. SCHRITT 8 Das Mitteltonlautsprecherkabel an den Anschluss des Tieftongehäuses anschließen: Zunächst einstecken und dann nach rechts drehen, damit es richtig einrastet. SCHRITT 9 Das Aluminiumgitter wieder auf dem Gehäuse der Mitteltöner platzieren und alle...
PLATZIERUNG DER | LAUTSPRECHER WANDMATERIAL Die Abmessungen Ihres Hörraums wirken sich nicht so sehr auf die Klangqualität aus wie die Position der Lautsprecher, daher Dicke Wände bieten eine gute Kontrolle empfehlen wir eine sorgfältige Platzierung. über die Bassausdehnung sowie eine Je besser die Positionierung, desto besser akustische Isolierung.
Seite 31
Faktoren empfiehlt, sie zwischen den Lautsprechern oder an der Seite des Systems Wenn Ihr Hörraum eher klein ausfällt und das zu platzieren. Das Gold Note Galileo Rack System zu nahe an der gegenüberliegenden verfügt über ein spezielles gebogenes Wand steht, sollten Sie erwägen, die Design, welches die Schallwellen effektiv zu Wand mit dicken Vorhängen oder anderen...
Seite 32
Hörplatz sollte ungefähr so groß sein wie in der Abbildung unten dargestellt. Gleichfalls sollte der Abstand zwischen den einzelnen Lautsprechern und der näheren Seitenwand ungefähr gleich groß sein wie der Abstand zwischen ihnen und der Rückwand. XS-85 XS-85 Abstand Lautsprecher Hörpunkt...
| PRODUKTREGISTRIERUNG GEWÄHRLEISTUNG PRODUKTREGISTRIERUNG Alle Gold Note Geräte verfügen über eine Bitte registrieren Sie das Produkt innerhalb Gewährleistung bezüglich fehlerhafter von 15 Tagen nach dem Kauf über das Materialien und Verarbeitung. Für zugehörige Formular auf unserer Webseite: Reparaturen und Probleme jeglicher Art www.goldnote.it/product-registration...
Seite 34
| FEHLERBEHEBUNG PROBLEM URSACHE LÖSUNG Aus den Lautsprechern Die Lautsprecher sind Prüfen Sie, ob das System kommt ein brummendes nicht nicht richtig und der Rest des Raums Geräusch. geerdet. richtig geerdet sind. Die Verbindungskabel Verwenden Sie nur für den Ein- und/oder abgeschirmte Kabel.
Seite 35
Grazie per aver acquistato una delle nostre unità e benvenuto nel mondo di Gold Note, dove trasformiamo l’audio e la musica High- End in un’esperienza completamente nuova. Maurizio Aterini, fondatore di Gold Note...
Gold Note non ha la responsabilità per lesioni da ribaltamento. ogni uso improprio di questa unità. Scollega il prodotto dalla corrente durante i temporali o quando non viene utilizzato per lunghi periodi di tempo.
Seite 37
GOLD NOTE - Informazioni sulla corretta gestione dei Rifiuti da Apparecchiature Elettriche ed Elettroniche (RAEE) domestiche ai sensi della Direttiva Europea 2012/19/EU Il simbolo del cassonetto barrato riportato sull’apparecchiatura o sulla sua confezione indica che il prodotto alla fine della propria vita utile deve essere raccolto separatamente dagli altri rifiuti per permetterne un adeguato trattamento e riciclo.
| INDICE SPECIFICHE TECNICHE DISIMBALLAGGIO E ASSEMBLAGGIO CONNESSIONE DEI DIFFUSORI POSIZIONAMENTO DEI DIFFUSORI PUNTO DI ASCOLTO REGISTRAZIONE PRODOTTO RISOLUZIONE PROBLEMI CONTENUTO DELLA | CONFEZIONE PIEDINI SOTTO XS-85 PUNTA CHIAVE A VITE MANUALE BRUGOLA M4x40mm UTENTE con rondelle...
Kg. 80 (a coppia) - imballato Impedenza nominale: 4Ω Tweeter: 1.1” a cupola in seta Mid-woofer: Cono da 5,5” Sub-woofer: Cono interno da 6” Alimentazione suggerita: min. 20W Max potenza applicata: 150W RMS Crossover: 70Hz e 2000Hz @ 12dB/Oct. Connettori: Gold Note dorati nickel-free...
DISIMBALLAGGIO E | ASSEMBLAGGIO Piedi (x4) M4x40 (x6) Ripetere ogni passo per entrambe le casse. FASE 1 FASE 3 Aprire la scatola della base e rimuoverla Prendere la base come mostrato delicatamente, quindi posizionare le scatole nell’immagine sopra e utilizzare le guide per di mid-high e woofer sul pavimento e aprirle.
Seite 42
FASE 4 FASE 6 Una volta assemblata la base, prestare Svitare le viti e rimuovere la griglia ventilata la massima attenzione nel capovolgere il in alluminio posta sul retro del cabinet mid- cabinet e assicurarsi di proteggerlo con high, come mostrato nell’immagine. materiale morbido per evitare danni alle superfici.
Seite 43
Cavo Mid-High M4x40 (x4) FASE 7 Fissare tra loro i cabinet mid-high e woofer con le quattro viti a brugola M4x40 in dotazione, come mostrato in figura. FASE 8 Connettere il cavo Mid-High al connettore del woofer: inserirlo e girare in senso orario in modo da bloccarlo correttamente in posizione.
Seite 44
| CONNESSIONE DEI DIFFUSORI CONNESSIONE STANDARD XS-85 DESTRO XS-85 SINISTRO AMPLIFICATORE FINALE RIGHT LEFT...
Seite 45
CONNESSIONE BI-WIRING XS-85 DESTRO XS-85 SINISTRO AMPLIFICATORE FINALE RIGHT LEFT...
POSIZIONAMENTO DEI | DIFFUSORI PAVIMENTO Le dimensioni della stanza di ascolto influiscono meno sulla qualità audio rispetto al corretto posizionamento dei diffusori Pavimenti in marmo e pietra dura quindi consigliamo di posizionarli con sono difficili da gestire a causa della cura.
Seite 47
PARETE POSTERIORE RACK La parete posteriore può essere trattata I rack sono influenzati dal design e dal come le pareti laterali, adottando materiale utilizzato, a seconda di questi accorgimenti per favorire la diffrazione del fattori devono essere posizionati tra i suono mediante pannelli diffusori o mobili diffusori o a lato dell’impianto.
Seite 48
Se possibile, la distanza tra un diffusore e la parete vicina dovrebbe essere uguale alla distanza tra i due diffusori. XS-85 XS-85 Distanza tra i diffusori Punto di ascolto...
Seite 49
| REGISTRAZIONE PRODOTTO REGISTRAZIONE PRODOTTO GARANZIA Si prega di registrare il prodotto tramite Tutti i prodotti Gold Note sono coperti da l’apposito form sul nostro sito entro e non garanzia in caso di malfunzionamento o oltre 15 giorni dall’acquisto: difetti di produzione.
| RISOLUZIONE PROBLEMI PROBLEMA CAUSA SOLUZIONE Uno o entrambi i diffusori C’è un problema di Controllare la messa a emettono un ronzio. messa a terra. terra dell’impianto. I cavi di interconnessione Utilizzare sempre cavi in entrata/uscita non sono schermati. schermati. La musica è...
