whether the teeth are jammed in the workpiece. If the saw
blade jams, it can move out of the workpiece or cause spring-
back when the saw is restarted.
d) Support large plates to reduce the risk of spring-back
due to a jammed saw blade. Large plates can bend under
their own weight. Plates must besupported on both sides, not
only near the sawing gap, but also at the edge.
e) Do not use any blunt or damaged saw blades. Saw
blades with blunt or improperly aligned teeth cause increased
friction, saw blade jamming and spring-back due to an
excessively tight sawing gap.
f) Before sawing, fix the cutting depth and cutting angle
settings. If the settings change during sawing, the saw blade
can jam, resulting in spring-back.
g) Be particularly careful when sawing existing walls or
other areas where you cannot see what is there. During
sawing, the cutting saw blade can jam in hidden objects and
cause spring-back.
FUNCTION OF THE BOTTOM PROTECTIVE HOOD
a) Before each use, check whether the bottom protective
hood closes properly. Do not use the saw if the bottom
protective hood does not move freely or close right away.
WARNING!
Do not insert battery before the tool is
completely assembled.
ASSEMBLY
Mounting the saw blade (fig.3)
1. Press down the spindle lock knob(12) and hold it in lock
place.
2. Using the hex key spanner to loosen the blade bolt.
3. Rotate the saw blade cover, then put the blade onto the
spindle.
4. Fasten the blade bolt again.
Mounting the parallel guide fence (fig. 4)
1. Using the hex spanner to loosen the lock bolt (3).
2. Silde the parallel guide fence into the slot on the base.
3. Adjust it to the desire position and fasten the lock bolt.
Adjusting the cutting depth (fig. 5)
1. Loosen the lock knob (15).
2. Push the baseplate downside.
3. Adjust it to the desire position and fasten the lock knob
again.
Adjusting the bevel cutting angle (fig. 6)
1. Loosen the lock knob (2).
2. Flip the baseplate to the bevel angle.
3. Adjust it to the desire position and fasten the lock knob
again.
Connecting the dust extraction tube (fig. 7)
Plug the small head into the dust exhaust port (13), and then
connect the big head with the dust vaccum cleaner.
Mounting the battery pack (fig. 8)
Align the battery pack slot with the battery foot on the tool, and
then push downward, until completely mounted.
To disassemble it, just keep pressing the red battery pack knob
and pull backward.
Switching on the laser guider (fig. 9)
This device equipped with a laser guider.
MAINTENANCE
●
Warning: Switch off and remove battery from power tool before adjusting or cleaning.
Never clamp or bind the bottom protective hood in an
open position. If the saw accidentally falls to the ground, the
bottom protective hood may be bent. Open the protective
hood using the pull lever and make sure that it moves freely
and does not touch the saw blade or other parts atall cutting
angles and depths.
b) Check the function of the springs for the bottom
protective hood. If the bottom protective hood and spring
do not work properly, have the saw serviced before using
it. Damaged parts, sticky deposits or accumulations of chips
cause the bottom protective hood to work with a delay.
c) Only open the bottom protective hood by hand for
special cuts, such as "plunge and angular cuts". Open
the bottom protective hood with the pull lever and release
it as soon as the saw blade cuts into the workpiece. For all
other sawing, the bottom protective hood should work
automatically.
d) Do not place the saw on the work bench or the floor if
the bottom protective hood is not covering the saw blade.
An unprotected saw blade that is still running will move the
saw in the direction opposite of the cutting direction and cut
whatever is in its way. Pay attention to how long the saw
blade remains running.
Before using it, mark a cut line with a pencil and then press
the laser switch (11) on. Let the laser line match the mark line.
Switching on / off the tool (Fig. 10)
This tool is equipped with a safety lock-off switch.
To start the tool, using your finger to press the safety lock-off
button (6) and hold it, then press the switch trigger (7) down.
The tool will start.
To switch off the tool, just release the switch trigger, the tool
will come to stop.
Battery Charging (Fig.11)
1. Plug the battery charging into the socket; The power
indicator light on green.
2. Slide the battery pack into the slot of battery chrger, after
hear a click, the battery pack was secured. The power
indicator light off, and meanwhile the charging indicator
light on red. The charging process starts.
3. After around 2hours (4.0Ah battery), the charging
indicator light will off,and meanwhile the power indicator
light green on again. It denotes the charging process is
completely finished.
4. Pull out the charger plug, and then pull off the battery
pack form charger.
Charging tips (Fig.12)
After using, the battery pack probably a little bit hot. In that
case, the battery pack can not be charged in.It need to have a
rest, let it cool down.
Battery volume indicator (fig. 13)
The battery pack has a feature to indicator which volume
status. To show this feature, just press the button on the
housing.
0 light on means the volume remains below 10%;
1 lights on means the volume remains 10% to 25%
2 lights on means the volume remains 25% to 50%
3 lights on means the volume remains 50% to 75%
4 lights on means the volume remains 75% to 100%
