English | 23
ing tool. The adapter plate can be fastened to the bottom, back and top side
of the measuring tool.
Check that the measuring tool is firmly secured.
When the adapter plate is mounted on the back, the height of the measuring
tool can be aligned. When it is mounted on the top or bottom, the measuring
tool can be aligned sideways. Turn the fine adjustment screw (2) of the ad-
apter plate to align the laser line with a reference point.
Laser Goggles (Accessory)
The laser goggles filter out ambient light. This makes the light of the laser ap-
pear brighter to the eye.

Maintenance and Service

Maintenance and Cleaning

Keep the measuring tool clean at all times.
Never immerse the measuring tool in water or other liquids.
Wipe off any dirt using a damp, soft cloth. Do not use any detergents or
solvents.
The areas around the outlet aperture of the laser in particular should be
cleaned on a regular basis. Make sure to check for lint when doing this.

After-Sales Service and Application Service

Our after-sales service responds to your questions concerning maintenance
and repair of your product as well as spare parts. You can find explosion
drawings and information on spare parts at: www.bosch-pt.com
The Bosch product use advice team will be happy to help you with any ques-
tions about our products and their accessories.
In all correspondence and spare parts orders, please always include the
10‑digit article number given on the nameplate of the product.
Great Britain
Robert Bosch Ltd. (B.S.C.)
P.O. Box 98
Broadwater Park
North Orbital Road
Denham Uxbridge
UB 9 5HJ
Bosch Power Tools 1 609 92A 64W | (11.12.2020)
