Gerätezeichnungen
Adapter cable
(Included in delivery)
CN 1
CN1 (MCP)
NO.
Pin definition
1
NC
2
NC
NC
3
4
IN (VBAT)
5
GND
6
NC
Robert Bosch GmbH
USB connector (Cream white)
Connect to USB socket "Audio"
with cable 7 620 280 112
(Cable not included in delivery)
USB connector (Nut brown)
Connect to USB socket "Phone"
with cable 7 620 280 112
(Cable not included in delivery)
USB connector (Claret violet)
Connect to CM-C 19
with cable 7 620 280 127
(Cable not included in delivery)
7 620 200 073 | 09.2020
de | 5
