78/143 Bosch Rexroth AG
Parametrierung
Rexroth IndraControl S67 Profinet-Koppler 8 digitale Eingänge (M8)
Konfiguration: 2 SSI Encoder /X3/X4)
Parameter
Diagnosis: Undervoltage ULS
Diagnosis: Undervoltage UA
Field supply at X3/X4
Diagnosis: Short circuit sensor supply
Clock frequency [kHz]
Singleturn data length [bit]
Multiturn data length [bit]
Encoding format
Parity
DOK-CONTRL-S67PNBKDI8*-AP04-DE-P
Beschreibung
- disabled
- enabled
- disabled
- enabled
- 5 V
- 24 V
- disabled
- enabled
- 62.5
- 125
- 250
- 500
- 1000
- 2000
- 8 ... 23
- 13
- 0 ... 15
- 12
- Binary code
- Gray code
- none
- even
- odd
