7. Technical data
7.1

Exhaust gas measurement

Component Measuring range
CO 0.000.. 10.00 % by vol
CO 0.00.. 18.00 % by vol
2
HC 0.. 9999 ppm by vol
O 0.00.. 22.00 % by vol
2
Lambda 0.500.. 9.999
CO 0.00.. 10.00 % by vol
vrai
(not in Germany)
NO 0.. 5000 ppm by vol
Accuracy class 1 and class 0 as per OIML R99 Ed. 1998
7.2 Power supply
Property
Input voltage (DC)
Power (P)
7.3 Temperature measurement/engine
speed measurement
Temperature
Oil temperature probe
Engine speed (gasoline)
BEA 040/BDM 300
*)
Engine speed (diesel)
BEA 040/BDM 300
*)
Special accessories
*)
7.4

Dimensions and weights

Property
Dimensions W x H x D:
Weight (without accessories)
Robert Bosch GmbH
Resolution
0.001 % by vol
0.01 % by vol
1 ppm by vol
0.01 % by vol
0.001
0.01 % by vol
1 ppm by vol
Value/range
11 V – 16 V
20 W
Min. Max.
-20°C 150°C
Min. Max.
400 min-1 8000 min-1
Min. Max.
400 min-1 6000 min-1
Value/range
370 x 190 x 230 mm
14.6 x 7.5 x 9.1 inch
5,2 kg
11.5 lb
Technical data | BEA 055 | 25
7.5 Temperature/atmospheric pressure
limits
Property
Operation
Storage and transport
Atmospheric pressure
7.5.1 Air pressure
Property
Storage and transport
Operation (at 25°C and 24 h)
Measurement accuracy
7.5.2 Air humidity
Property
Storage and transport
Operation
Measurement accuracy
7.6 MID environment categories
Class
Mechanical
Electromagnetic
7.7 Noise emissions
Property
Workplace emission sound pressure
level as per EN ISO 11204
Sound power level as per
DIN EN ISO 3744
en
Value/range
5 °C – 40 °C
41 °F – 104 °F
-25 °C – 60 °C
-13 °F – 140 °F
700 hPa − 1060 hPa
Value/range
700 hPa – 1060 hPa
700 hPa – 1060 hPa
700 hPa – 1060 hPa
Value/range
<75 %
<90 %
<90 %
Level
M1
E2
Value/range
< 70 dB(A)
< 72 dB(A)
|
