1. Description

The party heater is used outdoors to heat nearby
areas. A burner inside the perforated plate body
produces the necessary heat, which is radiated to
the immediate surroundings by an aluminium
reflector as well as by the perforated plate itself.
The party heater has to be set up on a level,
incombustible surface with no - or only a very slight -
gradient. Its center of gravity can be lowered
considerably by filling sand in the foot.
To make it easier to change the gas bottle, the body
can be raised and locked in place on the appliance
itself.
The party heater is designed to work only with
propane-butane (liquefied gas). It is connected
directly to the gas bottle by means of a DVGW-tested
and approved hose pipe and a liquefied gas
regulator (outlet pressure 50 mbar,
capacity 1,5 kg/h). The following regulations have to
be observed and adhered to when making the
connection:
Technical regulations concerning liquefied gas
(e.g. TRF)
Guidelines published by liability insurance
associations concerning the use of liquefied gas
in special applications

2. Technical data

Dimensions Overall height:
Reflector diameter:
Power rating:
Consumption:
Fuel:
Ignition:
Monitoring:
Regulator
Gas supply
25.10.2001 11:00 Uhr
To start the heater, open the gas bottle, „turn" the
knob to high setting, „press" the knob (for approx. 10
sec.) and „actuate" the piezo igniter.
The regulator knob has the settings „zero", „high"
and „low". Infinitely variable intermediate settings are
possible. A thermoelectric ignition cut-out prevents
gas escaping if there is no flame.
The foot, body, connecting piece and top are made
of powder-coated steel for outdoor duty.
The perforated body plate and burner are made of
stainless steel.
The reflector shade is made of aluminium.
2,165 mm
950 mm
10.6 kW
approx. 0.8 kg/h in high setting
Propane/butane liquefied gas
Piezo igniter
Thermoelectric flame monitor
Infinitely adjustable
Gas bottles up to 11 kg
