3.5 Sliding on the body
3.6 Reflector / Heating element / Top
The heating element is supplied already assembled
with its fittings, top and hose.
Important!
Do not kink or damage the hose.
3.7 Inserting the gas bottle
Lift the body and rest it between the screw heads
on the connecting piece.
Connect the hose to the pressure regulator.
Connect the pressure regulator to the gas bottle.
Use leakage spray or a foaming agent to test the
joints for leaks. Never test with a naked flame!
25.10.2001 11:00 Uhr Seite 11
3x washer Ø 12.5
3x raised cheesehead screw
Gas pipe
M6x12
