2.2 Items supplied
Please check that the article is complete as
specifi ed in the scope of delivery. If parts are
missing, please contact our service center or the
store where you made your purchase at the latest
within 5 work days after purchasing the article and
upon presentation of a valid bill of purchase. Also,
refer to the warranty table in the service informati-
on at the end of the operating instructions.
•
Open the packaging and take out the equip-
ment with care.
•
Remove the packaging material and any
packaging and/or transportation braces (if
present).
•
Check to see if all the items are supplied.
•
Inspect the equipment and accessories for
transport damage.
•
If possible, keep the packaging until the end
of the guarantee period.
Hazard!
The equipment and packaging material are
not toys. Do not let children play with plastic
bags, foils or small parts. There is a risk of
choking and suff ocating!

3. Intended use

The operating instructions as supplied by the ma-
nufacturer must be kept and referred to in order
to ensure that the equipment is properly used
and maintained. The instructions contain valuable
information on operating, maintenance and servi-
cing conditions.
The equipment is suitable for attaching to a lawn
tractor. The equipment may be attached only to
machines approved by the manufacturer and in
accordance with its intended use. Any other use
is deemed to be a case of misuse. The user/ope-
rator and not the manufacturer will be liable for
any damage or injuries of any kind resulting from
such misuse.
The manufacturer will not be liable for any dama-
ge resulting from unauthorized modifi cations to
the equipment.
Please note that our equipment has not been de-
signed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
equipment is used in commercial, trade or indust-
rial businesses or for equivalent purposes.
GB

4. Technical data

Max. working width: ..................................118 cm
Swiveling range: .............. 30° / 15° / 0° / 15° / 30°
Clearing bar: ............................................Rubber
Skids: .......................................Height adjustable
Weight: ........................................................44 kg

5. Before starting the equipment

Assembling the components
Some parts of the equipment come disassem-
bled. For quick and easy assembly, read and
follow the instructions below.
5.1 Mounting the support frame to the tractor
1. Before undoing the screws on the right and
left mark the position of the motor hood
mount with a pen and remove the cable ties
(Fig. 6).
2. Remove the screws on the right and loosely
mount the right part of the support frame to
the tractor (Fig. 7) (For the positions of the
screws, circlips and washers refer to Fig. 2.)
3. Remove the screws on the left and then also
mount the left part of the support frame loose-
ly to the tractor (Fig. 8).
Important! On some models the clasp for the
magnetic coupling is installed at the position
for the rear hole of the support frame. In this
case remove the nut of the clasp and screw
on the support frame and clasp using the pro-
vided special nut and washer. If the hole is not
occupied, use the special nut and a standard
M8x40 screw (for the positions of the screws,
circlips and washers refer to Fig. 2).
4. Screw both support frame parts together (Fig.
8).
Important! Assemble the countersunk screw
from the bottom up.
5. Tighten all screws. In doing so ensure that
the motor hood mounts are aligned in ac-
cordance with the initially created marks.
6. Reattach the cable to the frame using cable
ties.
