Switching On/Off; To Switch The Tv Off; First Time Installation - JVC 0417MTH-VT-VT Bedienungsanleitung

Switching On/Off

To Switch the TV On
Connect the power cord to the 220-240V AC, 50 Hz.
To switch on the TV from standby mode either:
• Press the " - (Standby)" button, "P+/P- - (Pro-
gramme +/-)" or a numeric button on the remote
control.
• Press the side function switch briefly so that the TV
comes on from standby.

To Switch the TV Off

Press the " - (Standby)" button on the remote
control or press the side function switch until the TV
switches into standby mode.
To power down the TV completely, unplug the
power cord from the mains socket.
Note: When the TV is switched into standby mode, the
standby LED can blink to indicate that features such as
Standby Search, Over Air Download or Timer is active. The
LED can also blink when you switch on the TV from standby
mode.

First Time Installation

When turned on for the first time, the language
selection screen is displayed. Select the desired
language and press OK.
On the next screen, set your preferences using the
directional buttons.
Notes: Depending on the Country selection you may be asked
to set and confirm a PIN at this point. The selected PIN cannot
be 0000. You have to enter it if you are asked to enter a PIN
for any menu operation later.
M7(*) operator type will be defined according to the Language
and Country selections that you made in the First Time
Installation.
(*) M7 is a digital satellite service provider.
About Selecting Broadcast Type
Digital Aerial: If Digital Aerial broadcast search
option is turned on, the TV will search for digital
terrestrial broadcasts after other initial settings are
completed.
Digital Cable: If Digital Cable broadcast search
option is turned on, the TV will search for digital cable
broadcasts after other initial settings are completed.
According to your other preferences a confirmation
message may be displayed before starting to search.
Select YES and press OK to proceed. To cancel
operation, select NO and press OK. You can select
Network or set values such as Frequency, Network
ID and Search Step. When finished, press OK button.
Note: Searching duration will change depending on the
selected Search Step.
Satellite(**): If Satellite broadcast search option
is turned on, the TV will search for digital satellite
broadcasts after other initial settings are completed.
Before satellite search is performed some settings
should be made. Before the satellite search starts, a
menu will be displayed where you can select to start
an M7 operator installation or a standard installation.
To start an M7 operator installation set the Install
Type as Operator and the Satellite Operator as the
related M7 operator. Then highlight Preferred Scan
option and set as Automatic channel scan and
press OK to start the automatic search. These options
can be preselected depending on the Language
and Country selections that you made in the earlier
steps of the first time installation process. You may be
asked to select HD/SD or country specific channel list
according to your M7 operator type. Select one and
press OK to proceed.
Wait till the scan is finished. Now the list has been
installed.
While performing an M7 operator installation, if you
want to use the satellite installation parameters that
differ from the default settings select the Preferred
Scan option as Manual channel scan and press the
OK button to proceed. Antenna Type menu will be
displayed next.
In order to search for satellite channels other than
M7 channels you should start a standard installation.
Select the Install Type as Standard and press the
OK button to proceed. Antenna Type menu will be
displayed next.
There are three types of antenna selection. You can
select Antenna Type as Direct, Single Satellite
Cable or DiSEqC switch by using " " or " " buttons.
• Direct: If you have a single receiver and a direct
satellite dish, select this antenna type. Press OK to
continue. Select an available satellite on the next
screen and press OK to scan for services.
• Single Satellite Cable: If you have multiple
receivers and a single satellite cable system, select
this antenna type. Press OK to continue. Configure
settings by following instructions on the next screen.
Press OK to scan for services.
• DiSEqC switch: If you have multiple satellite dishes
and a DiSEqC switch, select this antenna type.
Press OK to continue. You can set four DiSEqC
options (if available) on the next screen. Press OK
button to scan the first satellite in the list.
(**) If this feature is supported by your TV.
Analogue: If Analogue broadcast search option is
turned on, the TV will search for analogue broadcasts
after other initial settings are completed.
Additionally you can set a broadcast type as your
favourite one. Priority will be given to the selected
broadcast type during the search process and the
channels of it will be listed on the top of the Channel
List. When finished, press OK to continue.
English - 9 -
