STR 100 microSAT

Technische Daten

Programmspeicherplätze ........................................... 199 TV / Radio
Eingangsfrequenzbereich ......................................... 950...2150MHz
SAT-ZF-Eingang .............................................................................. 1
ZF-Bandbreite ................................................................. 18 / 27MHz
LNB-Power ....................................................... 14/18V max. 300mA
LNB-Schaltsignal ..................................................................... 22kHz
Ton-Frequenzbereich ................................................. 5,0...9,77MHz
Stereo ...................................................................... Panda Wegener
Ton-Bandbreite ...................................................... 130kHz...280kHz
Ton-Deemphasis umschaltbar .......................................... 50µs / J17
Videohub ............................................................... 16 / 22,5 / 25MHz
Videopolarität ............................................................ positiv / negativ
Anzeige LED ................................. Betriebsanzeige in der IR-Mouse
OSD-Menü ........................................................................... Englisch
Scartbuchsen ....................................................... TV, VCR, Decoder
Netzspannung mit externen Netzteil ............................... 220...240V
Batterieanschluß .................................................................. 12...24V
Regelbereich des Schaltnetzteils .................................... 185...265V
Netzfrequenz ..................................................................... 50 / 60Hz
Fernbedienung ............................................................... TP 720 SAT
Abmessungen (BxHxT) .......................... ca. 116 x 218,5 x 48,5 mm
Gewicht ............................................................................. ca. 0,42kg
Leistungsaufnahme bei Vollast (mit LNC) ............................ ca. 13W
Leistungsaufnahme in Standby ........................................... ca. 0,5W
Modulübersicht / Module List
GRUNDIG Service

Technical Data

Programme memory locations ................................... 199 TV / Radio
Input frequency range ............................................... 950...2150MHz
SAT IF-input ..................................................................................... 1
IF bandwidth ................................................................... 18 / 27MHz
LNB power ....................................................... 14/18V, max. 300mA
LNB switching signal ............................................................... 22kHz
Sound frequency range .............................................. 5.0...9.77MHz
Stereo ...................................................................... Panda Wegener
Audio bandwidth .................................................... 130kHz...280kHz
Sound de-emphasis, switchable ....................................... 50µs / J17
Video deviation ..................................................... 16 / 22.5 / 25MHz
Video polarity ........................................................ positive / negative
Display LED ...................................... function indication in IR mouse
OSD menu ............................................................................. English
Scart sockets ....................................................... TV, VCR, Decoder
Mains supply from external supply unit ........................... 220...240V
Battery connection ............................................................... 12...24V
Control range of switched mode power supply ............... 185...265V
Mains frequency ................................................................ 50 / 60Hz
Remote control handset ................................................ TP 720 SAT
Dimensions (WxHxD) ............................. ca. 116 x 218.5 x 48.5 mm
Weight ............................................................................... ca. 0.42kg
Power consumption at full load (with LNC) .......................... ca. 13W
Power consumption in standby ........................................... ca. 0.5W
Chassis
Tuner
IR-Einheit, SAT-Mouse
IR Unit, SAT mouse
Fernbedienung TP 720 SAT
Remote Control TP 720 SAT
Allgemeiner Teil / General Section
29702-338.01
29504-201.77
29633-836.01
29642-059.18
1 - 3
