3. Technical data

Charging unit:
Input: .......................... 200-260V~50-60Hz, 72W
Output: ................................... 21 V DC, 3000mA
Important.
The charging unit is allowed to be used only for
the lithium-ion batteries of the Power-X-Change
series!
Power-X-Change
•
18 V, 1,5 Ah, 5 Li-Ion Cells
•
18 V, 3,0 Ah, 10 Li-Ion Cells
•
18 V, 5,2 Ah, 10 Li-Ion Cells
4. Operation (Fig. 2+3)
1. Pull the battery pack (a) out of the handle,
pressing the pushlock button (b) as you do
so.
2. Check that your mains voltage is the same as
that marked on the rating plate of the battery
charger. Insert the power plug of the charger
(1) into the mains socket outlet. The green
LED will then begin to fl ash.
3. Insert the battery pack (a) into the battery
charger (1).
4. In section 8 „Charger indicator" you will fi nd a
table with an explanation of the LED indicator
on the charger.
If the battery fails to charge, please check
•
whether there is voltage at the socket outlet
•
whether there is good contact at the charging
contacts of the charging unit
If the battery still fails to charge, send
•
the charging unit
•
and the screwdriver to our customer service
center.
Customer service:
ISC GmbH International Service Center
Eschenstrasse 6 · D-94405 Landau/Isar, Germa-
ny www.isc-gmbh.info
Timely recharging of the battery will help it serve
you well for a long time. You must recharge the
battery when you notice that the power of the
cordless screwdriver drops.
Anl_Power_X_Charger_SPK7_tuev.indb 14 Anl_Power_X_Charger_SPK7_tuev.indb 14
GB
Mounting the charging unit on a wall (Fig. 4)
The charging unit can also be mounted on a wall.
The correct dimensions for drilling holes in the
wall can be found on the back of the charging unit.
Distance
≥ 10 cm from wall (right + left)
≥ 100 cm from ceiling
Important.
When mounting on a wall you must use suitable
screws, e.g. 3.5 mm pan-head screws, in order to
prevent damage to the housing and risk of falling.

5. Cleaning and maintenance

Always pull out the power plug before starting any
cleaning work.
The equipment is not allowed to be stored in a
damp location or where there are caustic gases.
Keep it in a dry place out of the reach of children.
5.1 Cleaning
Keep the surface of the equipment clean and
wipe it only with a dry cloth.
5.2 Maintenance
There are no other parts inside the equipment
which require maintenance.
The equipment is not allowed to be taken apart. If
the equipment is damaged, contact your supplier
or the manufacturer.

6. Disposal and recycling

The equipment is supplied in packaging to pre-
vent it from being damaged in transit. The raw
materials in this packaging can be reused or
recycled. The equipment and its accessories are
made of various types of material, such as metal
and plastic. Never place defective parts in your
household refuse. Ask your dealer or your local
council.
