Anleitung_NSMS_4300_ZZ_SPK7:Anleitung KGSZ 3050 SPK1
GB
Undo the clamping nut (13) and, holding the
handle (2), tilt the machine head (4) to the left to
the required angle dimension
(see also Section 7.5).
Re-tighten the locking nut (13) and make the cut
as described in Section 7.2.
7.8 Chip extraction (Fig. 1)
The saw is equipped with a chip collection bag (24).
The chip bag (24) can be emptied by opening the zip
fastener at the bottom.
7.9 Replacing the saw blade (Fig. 11)
Pull out the power plug.
Swing up the machine head (4).
Press the lever and swing up the saw blade
guard to the point where the recess in the saw
blade guard is above the flange bolt.
Press the saw shaft lock (17) with one hand while
holding the wrench (31) on the flange bolt with
the other.
Firmly press on the saw shaft lock (17) and
slowly rotate the flange bolt in clockwise
direction. The saw shaft lock engages after no
more than one rotation.
Now, using a little more force, slacken the flange
bolt in clockwise direction.
Turn the flange bolt until it is completely
removed.
Take the blade (5) off the inner flange and pull
out downwards.
Mount the new saw blade in reverse order and
fasten.
Important! The cutting bevel of the teeth, i.e. the
direction of rotation of the saw blade, has to
conform with the direction of the arrow marked on
the housing.
Clean the saw blade flanges thoroughly before
mounting the saw blade.
Reattach the movable blade guard (6) in reverse
order.
Before using the saw again, check that the safety
devices are in good working order.
Important: Every time that you change the saw
blade, check to see that it spins freely in the
groove of the turntable in both perpendicular and
45° angle settings.
7.10 Storage compartment for spare saw blade
(Fig. 13)
The saw is equipped with a storage compartment
(33) for a spare saw blade.
To open the storage compartment, pull the locking
knob (34) on the rear of the saw while pulling the
storage compartment out at the same time.
14
16.09.2008
7.11 Laser function (Fig. 12)
You can switch the laser ON and OFF with the
switch (a).
The laser (35) directs a beam onto the work-
piece.
Extremely precise cuts can be made using the
laser function.
8. Replacing the power cable
If the power cable for this equipment is damaged, it
must be replaced by the manufacturer or its after-
sales service or similarly trained personnel to avoid
danger.
9. Cleaning, maintenance and ordering
of spare parts
Always pull out the mains power plug before starting
any cleaning work.
9.1 Cleaning
Keep all safety devices, air vents and the motor
housing free of dirt and dust as far as possible.
Wipe the equipment with a clean cloth or blow it
with compressed air at low pressure.
We recommend that you clean the device
immediately each time you have finished using it.
Clean the equipment regularly with a moist cloth
and some soft soap. Do not use cleaning agents
or solvents; these could attack the plastic parts
of the equipment. Ensure that no water can seep
into the device.
9.2 Carbon brushes
In case of excessive sparking, have the carbon
brushes checked only by a qualified electrician.
Important! The carbon brushes should not be rep
laced by anyone but a qualified electrician.
9.3 Maintenance
There are no parts inside the equipment which
require additional maintenance.
Lubricate all moving parts at regular intervals.
9.4 Ordering replacement parts
Please quote the following data when ordering
replacement parts:
Type of machine
Article number of the machine
Identification number of the machine
Replacement part number of the part required
13:45 Uhr
Seite 14
