FIG.6 SHOWS THE COMPONENTS COMPRISING THE TRIPOLLAR STOP VX2 DEVICE
1. DEVICE BODY
2. TREATMENT HEAD
3. ELECTRODE
4. TEMPERATURE SENSOR
5. CONTROL PANEL
6. POWER SUPPLY CONNECTION
7. ORANGE INDICATION LIGHT

8. ON/OFF BUTTON

9. DMA BUTTON
10. LOW RF / LOW RF AND DMA
11. MEDIUM RF/ MEDIUM RF AND DMA
12. HIGH RF/ HIGH RF AND DMA
13. PROTECTIVE COVER
6.
6.
5.
9.
13.
1.
8.
10-12.
FIG.6
3.
4.
2.
7.
