TECHNICAL SPECIFICATIONS

Front frame (on wall) dimensions: 89mm (H) х 89mm (W) х 9mm (D)
Rear electronics package dimensions: 53mm (H) х 53mm (W) х 28mm (D)
Materials: Tempered glass panel, Flame retardant plastic
5 frame colors: White, Gloss Black, Matte Black, Silver, Chrome
6 glass colors: White, Black, Yellow, Green, Red, Blue
1 capacitive-touch button
Red and Blue LED backlights for button
10 brightness levels (adjustable) for button backlight
Operating temperature: 0°С to +50°С
Operating humidity: 10% to 95% RH
Power supply: 85-265VAC 50Hz/60Hz or 24-48VDC
Power consumption: <1W
1 channel relay output with resistive load up to 5A
Independent relay input (dry contact)
Relay switching with zero-cross technology
Relay life time: 100.000 switches
Internal ambient light sensor
Internal temperature sensor
- Measurement range: –30°C to +80°C
- Accuracy: ±0.5°C
Internal humidity sensor
- Measurement range: 0% to 80% RH
- Accuracy: ±3.0% RH
Software energy consumption logic
IP class: IP21
Z-Wave Plus V2 SDK: V7.11
Z-Wave 700 module: ZGM130S
Requires mounting to ush electrical junction box:
round, square or rectangular type – min. depth 40mm

Declaration of Conformity

Hereby, Heltun declares that the device is in compliance with directives:
EMC 2014/30/EU, LVD 2014/35/EU, RED 2014/53/EU, RoHS 2011/65/EU.
