UK
3. Using the supplied small „imbus" wrench screw the locking „mi bus" screw into hole in the hedge on the back of the handlebasr.
4. Miniscooter is now ready for use.
CREW
1. Put clamp (B) on handlebar (F). Then handlebar (F) with clamp (B) put on scooter fork (E) so that vertical part of fork (E) is in front part and slant part of the fork (E) is directed towards the scooter's
deck. After putting handlebar (F) on fork (E) put the clamp (B) as low as possible to fork (E).
2. Fit the four "imbus" /hexagonal/ screws (c) into the clip (b), so that heads of all four bolts are pointing to the same side. Then tighten the "imbus" screws using the supplied larger „imbus" wrench so that
the handlebars are properly secured against spontaneous loose.
3. Variant without PEG (H): put wheel (D) in scooter's fork (E), secure the wheel (D) with short imbus /hexagonal/ screws. Then tighten the imbus /hexagonal/ screws with supplied larger imbus wrench,
so that the wheel (D) is properly secured agains spontaneous loose.
3.1. Variant with PEG (H): put wheel (D) in scooter fork (E), then from left or right side attach the PEG (H) and secure the wheel (D) and PEG (H) with long imbus /hexagonal/ screws. Then tighten the
imbus /hexagonal/ screws with supplied larger imbus wrench, so that the PEG (H) and the wheel (D) are properly secured agains spontaneous loose.
4. Stick grip (I) on upper side of scooter's deck.
5. Miniscooter is now ready for use.
Tighten the clamp (B) in gradually by (three) four hexagon bolts (C) in the order of the top 1-2-3(-4) and repeat this tightening several times until the clamp (B) is fully fixed. This process needs to be
repeated again after the first ride.
Instructions for the decomposition of mini scooter
When composing mini scooter perform acts in the reverse order as when composing. Release the fuses by pushing the stem into the tube.
Basic instructions for using a mini scooter
1. Always check before every use tightening all screw connections (wheels must spin freely). In case of any damaged screws, nuts and accessories replacement is necessary. Do not use
with the damaged parts! Do not touch with bare hands or feet braking mechanism - when braking the temperature is high! When driving, braking is done by stepping to the rear wheel
fender. Wear shoes when driving.
2. Wear a helmet when riding (bicycle helmet, helmet in-line, we recommend protectors of joints and spine). Mini scooter is not a toy. It is designed for recreational freestyle riding. As a
beginner start with simple elements of freestyle riding. Recommended in the presence of an experienced freestyler.
3. Use original spare parts. Ask for them the dealer from whom you purchased the product. Repairs and maintenance do in authorized services.
4. Hub for turning the handlebars must be rotated freely /control even during the driving.
5. Mini scooter is not designed for riding on public roads. We recommend riding in places which are designed for a freestyle riding (skate parks). Not suitable for driving 2 persons simultaneously.
6. Mini scooter is designed for riding on smooth surfaces (asphalt, concrete, etc.). Do not use on surfaces contaminated by stones, branches or other objects that could cause blockage of
the wheels. Watch out for obstacles along the roads (eg, poles, bollards, etc.). Otherwise it could lead to injury.
7. When driving, consider the other citizens. Hold the handlebars with both hands, not run while driving a dog or other animals.
8. Any sharp edges arising from use eliminate immediately.
9. If bearings get wet, wipe it dry with a cloth and treat with oil.
10. Do not drive on the roads for motor vehicles, under fog, wet, poor visibility, after consuming alcohol or drugs (observe the regulations on restrictions of road safety).
11. Continuously check the mini scooter (even while driving).
12. If the wheel is too bald or mechanically damaged must be replaced.
13. A very important part of safe and trouble-free use of the product is the correct adjustment (wheel bearings, headset, tighten screw joints, etc.). To check these parts is necessary even
during driving, especially when you feel while driving mini scooter has different characteristics than at the beginning of the ride. Compliance with these conditions is important both for safety
and for the life of the product.
