Introduction
The FANTEC UMP-4U31-C is a super speed USB 3.0 hub providing 4 ports. You can
expand your PC's USB 3.0 interface with 4x USB 3.0 Superspeed host port,
supporting up to 5Gbps data transfer speed.
Speci cation:
Model: UMP-4U31-C
Input Interface: USB 3.0 Type-C (compatible to USB 3.0/2.0/1.1)
Output: USB 3.0 4 Ports, 5Gbps
LED Indication: Lights up during operation
System: Windows 7/8/8.1/10 Mac OS, Linux
Dimension: 110*30*10mm
Weight: 40g
Operating Environment: Working: 0~50
Features:
1. LED indicator for power status
2. Multiple USB 3.0 interface supports plug and play, hot-swap, it's easy to use
and carry
3. Supports USB 3.0 super speed (5Gbps) transmission, downward compatible
to USB 2.0/1.1
4. USB charging detection for mobile devices
5. Driver free, supports Windows 7/8/8.1/10; Mac OS; Linux
Package Contents:
1. USB 3.0 Hub 1x
2. User Manual 1x
Description
1. Power LED
2. USB 3.0 Interface
3. Cable
o o
C; Storage: -20~50 C
User Operation
USB HUB connection
a) Connect the USB type-C connector of the cable to your computer's
USB interface. At this point, the USB host ports will be ready to use.
b) Connect all kind of USB storage devices to the USB host port of the HUB.
At this point you will nd new storage devices at your computer's disk
managent and can store your data.
c) Next to the function mentioned above, it's possible to charge mobile phones,
power bank or other battery powered USB devices. The charging speed
is depending on the power delivery of your computer's USB interface.
Application:
The FANTEC USB HUB can be used to connect USB3.0 disk drives, USB pen
drives, high-resolution cameras ,video surveillance cameras, digital video
cameras, as well as multi-channel audio and other broadband peripherals, and
supports simultaneous connection of up to three USB 3.0 devices. The speed
can reach up to 5Gbps.
Contact:
service@fantec.de
www.fantec.de/en
Declaration of conformity
Hereby FANTEC GmbH declares that the model FANTEC UMP-4U31-C is in
compliance with the essential requirements and other relevant provisions of
directive RED 2014/30/EC.
A copy of the declaration of conformity can be found at
http://www.fantec.de/unternehmen/bestimmungenrichtlinien/ce/
Manual Version V1.0
FANTEC reserves the right to make changes without prior notice.
