OPERATING INSTRUCTIONS
ELECTRIC SCOOTER ASSEMBLY
Warning
Always switch off the electric scooter and disconnect the charger from wall socket before assembling or removing accessories!
N – Lift the column in upright position and secure with the locking ring
O – Connect both cables and insert the handlebar into the column
P – Connect the handlebar with the column using screws (included)
FOLDING DOWN THE E-SCOOTER
Q - Turn the locking ring
R –Loosen the locking clip
S – Fold the column
T – Press the hook to engage into the hole in the rear mudguard.
INSTALLATION OF THE BATTERY
U –Place the battery in the e-scooter horizontally
V – Connect the charging and power supply connector to the battery
W – Put the battery cover onto the battery
X – Tighten the screws clockwise
You can find images for labels in the CZ version of this manual.
HOW TO RIDE THE ELECTRIC SCOOTER
1. Press and hold the On/Off button for 2 seconds.
2. Place one foot on the deck and use the other one to kick off the ground.
3. After you reach a sufficient speed and you feel stable, place your other foot on the deck of the electric scooter.
4. After start, slightly press the accelerator and carefully turn the handlebars to change direction.
5. Press the ACCELERATOR button to accelerate. Be careful and do not ride too fast!
6. Press the brake lever and lightly step on the rear brake to brake.
7. When the electric scooter slows down enough, remove your foot from the deck. After the electric scooter stops
completely, put both your feet on the ground.
RANGE OF THE ELECTRIC SCOOTER
The range of the electric scooter can be affected by several factors, such as the weather, weight, battery charge and state
of the road. These are just main examples, each factor can affect the range and many of them can combine with each
other. Please bear in mind that the total range given in specifications is for reference only. The actual range can vary
greatly. Bear it in mind when using the electric scooter.

BATTERY SPECIFICATIONS

Follow these storage and charge instructions to extend battery lifespan and performance. Please pay special attention
to safety precautions and other specifications.
Battery specifications
Type
Charging time
Voltage
60
Li-ion battery
8-9 hours
36 V
SC7000 SC4500
Operating temperature
Charge temperature
Maximum charging voltage
Recommended storage time (-8 °C – 35 °C)
Maximum charging current
Input voltage
Frequency
Output voltage
Output current
Storage temperature
SAFE USING OF THE BATTERY
Stop using the battery in the following cases:
• Use the battery of the electric scooter only in accordance with local laws. Contact a qualified person to remove and
replace the battery.
• Do not touch any substances leaking from the battery. If the battery starts to produce an unpleasant odour or gets
too hot, stop using it.
• Do not use the electric scooter during charging. Always disconnect the battery from the charger before ride and
installation.
• Do not let children and animals touch the battery!
• To ensure proper operation of the battery, pay attention to the storage and charge temperature. Always observe
the temperature range given in the specifications.
• Always follow local laws when transporting lithium batteries. Lithium batteries are considered dangerous.
• The battery contains dangerous substances, never open the battery. Do not insert anything into the battery.
• It is forbidden to charge a lithium battery that has been over-discharged. These batteries represent a safety hazard,
hand them over to the appropriate collection point.
• If the internal temperature of the battery exceeds 45 °C, the protection system will be automatically activated.
• Do not charge the battery if the outdoor or indoor temperature exceeds 40 °C.
• Never leave the electric scooter on a direct sunlight. This could damage the battery.
• Use only original chargers to charge the electric scooter.
CHARGING METHODS
Method 1:
• Remove the battery from the e-scooter, remove the silicon cover on the
charging port, plug DC connector in battery´s charging port.
• If the signal lamp of the charger lights red, the charging process continues.
• If the signal lamp of the charger lights green, the charging process has been
completed.
Method 2:
• Remove the silicon cover on the charging port on the side of the e-scooter
and plug DC connector of the charger to battery´s charging port.
a – Power supply connector
b – Charging connector
c – Charging indicator
SC7000 SC4500
0 °C–35 °C
0 °C–35 °C
42 V
3 months when fully charged
2 A
100–240 V
50–60 Hz
42 V
2 A
-8 °C–35 °C
