Manual
ENG
Product Name
FlinQ Solar Lamp Geisha
Power/Lumen
1.5W Plus/220lm
LED
SMD2835*14 PCS (Front 12 PCS + Back
2 PCS)
Beam Angle
90ºc
Li-ion Battery
1200 mAh/3.7V (replaceable)
Solar Panel
0.7 Wp, mono-crystalline silicon
Detection angle/area
120ºc /<6 meters
IP Degree
IP65 Waterproof
24 months (battery 12 months war-
Warranty
ranty)
Lifespan
35.000 hours
Installation height
<4 meters
Packing
Blister Package (1x Solar Light, 1x
Color Page, 1x Accessory bag, 1x User
manual, 1x Measure card)
Solar Lamp Geisha
Installation
1. Hole
2. Expansion Plug
3. Screw
4. Mounting Hole
5. Button
1. Please use the card to measure hole position correctly and drill 2 holes
2. Fix 2 expansion plugs into the holes
3. Fix a screw to the lower expansion plug with a spare space. Insert the
4. Straighten the whole lamp and fasten the upper screw.
5. Press the button to adjust to demanded working mode.
Notice
1. This is a solar powered lamp, please install it in a location where there is
2. The lamp will automatically light up when it is dark.
3. Please note the lighting time depends on sunshine duration and
4. Built-in intelligent IC equipped with over-charge, over-discharge and
of 6mm
notch onto the screw.
enough sunlight.
weather.
over-voltage protection.
1
4
5
2
3
